Home > Lights & Lighting > LED Encapsulation Series > SMD LED > CE&RoHS Approval 0805 SMD LED Diode of Rgb
CE&RoHS Approval 0805 SMD LED Diode of Rgb
US$ 0.03 - 0.75
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Model Number:
GYX-SD-0805
Chip Material:
AlGaInP
Emitting Color:
Tri-Color(Red-Blue-Green)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Widely Used RGB 0805 Smd Led for Viewing SignUS$ 0.03 - 0.75MOQ: 100 Pieces -
Latest 2 Warranty Years 2.0V ROHS Certificate 0603 SMD LedUS$ 0.02 - 0.1MOQ: 500 Pieces
-
0603US$ 0.01 - 0.05MOQ: 1000 Pieces
-
GYX SMD LED of 0603, 3528, 5050, 1616, 3014 and 2121 Species With RGB & White Color and Full ColorUS$ 0.03 - 1MOQ: 100 Pieces
-
High Brightness Rgb 0603 Led Smd DisplayUS$ 1.2 - 15MOQ: 100 Pieces
Model Number
GYX-SD-0805
Chip Material
AlGaInP
Emitting Color
Tri-Color(Red-Blue-Green)
Place of Origin
Guangdong, China
Brand Name
GYX
Certification
CE
Specifications
Low Power ConsumptionLow price LED diode
With CE&RoHS approved
Specifications for LED Diode:
1.Electrical optical charactertistics(Ta25°C)
Parameter |
Symbol |
Min |
Type |
Max |
Unt |
Test Condition |
Luminous Intensity |
IV |
120 |
140 |
160 |
mcd |
IF=20mA |
Peak Wavelength |
lρ |
|
|
|
nm |
IF=20mA |
Dominant Wavelength |
ld |
620 |
625 |
630 |
nm |
IF=20mA |
Viewing angle |
2θ1/2 |
|
120 |
|
deg |
IF=20mA |
Forward Voltage |
Vf |
1.9 |
|
2.1 |
V |
IF=20mA |
Reverse Current |
IR |
|
|
5 |
uA |
VR=5V |
Suggestion Forward Current |
IF |
3 |
5-10 |
20 |
mA |
IF=20mA |
2.Absolute Maximum Ratings (Ta=25°C):
Parameter |
Rating |
Unit |
||
Reverse Voltage |
5 |
V |
||
Power Dissipation,Per Dice |
60 |
mW/chip |
||
Operating Temperature Ranger |
-25~+85 |
°C |
||
Storage Humidity |
45%~85% |
°F |
||
Storage Temperature Ranger |
-30~+85 |
°C |
||
Soldering Temperature |
|
|
260°C for 5 seconds |
|
Peak IF(ma) (1/10Duty Cycle 0.1ms Pulse Width) |
60 |
mA/chip |
||
Continuous Forward Current |
30 |
mA/chip |
||
3.Package dimension
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2000
Factory Size
30,000-50,000 square meters
Total Employees
501 - 1000 People
