2 mm Brushed finishes Aluminum Composite Panel from China Supplier
Surface coated : PET
Aluminum skin:0.10,0.12,0.15mm
Core: PE
Standard size:1220mm x2440m
A. Assessed by Bureau Veritas in ACP industry.
B.V., aka Bureau Veritas, formed in Antwerp in 1828, is one of the world's biggest global company in testing, inspection and certification services. Our factory was audited by B.V. and successfully received its certification shortly after the assessment. You can rest assured that everything related to our factory and our quality matches performance of a preferred suppllier.
B. Inherent Advantages in Cost
1, We are the only manufacturer ( Exterior Wall Cladding Insulation Panel Kitchen Panel Alucobond Prices ) located in the east of Guangdong. Labor cost is way much lower than those of other locations of Guangdong,Zhejiang,Jiangsu,Shandong,etc.
2, We own a PE(Composite Panel core) factory which allows us to avoid buying PE raw material from suppliers in market. We save cost for customers.
C. Excellent Quality
Over 80% of engineers have been working in our factory for more than 9 years since 2006. With their professional knowledge and experience,we have been supplying excellent quality Aluminium Composite Panel(ACP Panel) to customers in and abroad.
D. Professional Service Team
Your perception is our reality. A smooth process and strong finish is our aim on every project. Not only do we have the resources to meet the challenges of each project, we take great care in how our work is executed. Everyone of our service team is specialist in this business. They can help you with any questions related to ACP such as difference of material,prices,shipping,customs clearance,etc. You can reach our 24/7 service team at +86-15992563464(Wechat/Whatsapp)
PHYSICAL PROPERTIES
| Properties | 2 mm | 3 mm | 4 mm | 6 mm |
| Aluminum thickness, in (mm) | 0.010 (0.25) | 0.010 (0.25) | 0.020 (0.5) | 0.020 (0.5) |
| Weight, psf (kg/m2) | 0.59 (2.9) | 0.80 (3.9) | 1.12 (5.5) | 1.50 (7.32) |
| Coefficient of expansion, ASTM D696, in/in/°F | 13 × 10^-6 | 13 × 10^-6 | 13 × 10^-6 | 13 × 10^-6 |
| Tensile strength, ASTM E8, psi (MPa) | - | - | 6913 (48) | 4978 (35) |
| Yield strength, ASTM E8, psi (MPa) | - | - | 6429 (44) | 4466 (30) |
| Elongation | - | - | 13.50% | 17.50% |
| Thermal conductance, ASTM C976, Btu/(ft2 × h × °F) (W/(m2 × K)) | - | - | 10.75 (18) | 8.53 (14) |
| Minimum Drum peel, ASTM D1781, in-lb/in(N-mm/mm) | - | - | 22.5 (100) | 22.5 (100) |
| Thermal resistance, ft2 × h × °F/Btu (m2 × K/W) | - | - | 0.09 (0.016) | 0.12 (0.021) |
| Sound transmission coefficient, ASTM E413 | - | - | 26 | 26 |
FIRE PERFORMANCE PROPERTIES
| Properties | 4 mm | 6 mm | ||
| Surface burning characteristics, ASTM E84 | ||||
| Smoke developed index | 450 maximum | 450 maximum | ||
| Flamespread index | 25 maximum | 25 maximum | ||
| Vertical transmission, ASTM E108 (modified) | Passed | Passed | ||
| Ignition temperature, ASTM D1929 | ||||
| Flash ignition | 716° F (380° C) | - | ||
| Self-ignition | 752° F (400° C) | - | ||
| Rate of burning, ASTM D635 | CCI | - | ||
Below is general packing information for one 20'GP
1. Approximately 2,300 sheets(1220*2440*2.7MM) without package;
2. Approximately 2,100 sheets(1220*2440*3.0MM) without package;
3. Approximately 1,600 sheets(1220*2440*4.0MM) without package.
If you need wooden case packing or other specification of ACP,kindly let us know. We will provide detailed information so you can have an idea of loaded quantity and shipping cost.
