3.81mm Pluggable Terminal Block XS2ESDA 300V 10A With UL, CE, ISO, SGS,CQC Approved
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
XIONGSHI
Model Number:
XS2ESDA
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PCB Terminal Block XS2ESDV 300V 15A 5.0/5.08/7.62mm Pitch With UL, CE, ISO, SGS,CQC ApprovedUS$ 0.04 - 0.05MOQ: 100 Pieces -
5.08mm Pitch PCB Screw Terminal Block KDG126 5.08mm Pitch 300V 12ANegotiableMOQ: 1000 Pieces
-
5.08mm Pitch Pluggable Terminal Block XS2ESDV 300V 15ANegotiableMOQ: 1000 Pieces
-
Screw Clamp Terminal Block XS2ESDV 5.0mm 5.08mm 300V 15ANegotiableMOQ: 1000 Pieces
-
5.08mm Pitch Plug in Terminal Block XS2ESDV 300V 15ANegotiableMOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
XIONGSHI
Model Number
XS2ESDA
Type
Other, Plug-in Terminals
3.81mm Pluggable Terminal Block XS2ESDA 300V 10A
with UL, CE, ISO, SGS,CQC Approved
3.81mm Pluggable Terminal Block XS2ESDA 300V 10A
Product Description
Terminal Block Specification
| XS2ESDA -3.81mm 3.5mm Pitch | |
| Approval | UL |
| Electrical | |
| Rated voltage | 300V |
| Rated current | 10A |
| Wire range | 28-16AWG |
| Withstand Voltage | AC2000V for 1 minute |
| Insulation Resistance | 1000 mΩ / DC 500V |
| Materials | |
| Plastic Housing | PA66, UL94V-0 |
| Operation Temperature | -40℃- +105℃ |
| Terminal | Brass, Silve Plated |
| Screw | Steel, M2.0, Zinc Plated |
| Torque Value | 0.2Nm |
3.81mm Pluggable Terminal Block XS2ESDA 300V 10A
3.81mm Pluggable Terminal Block 300V 10A, Right Angle Pin Model: XS2EHDC
3.81mm Pluggable Terminal Block 300V 10A, Straight Pin Model: XS2EHDB
3.81mm Pluggable Terminal Block 300V 10A Model: XS2ESDV
3.81mm Pluggable Terminal Block XS2ESDA 300V 10A Model: XS2EHDL
3.81mm Pluggable Terminal Block 300V 10A Straight Pin Model: XS2EHDF
3.81mm Pluggable Terminal Block 300V 10A Model: XS2ESDV
