Stainless Steel Square Window Accessories Friction Stay Upvc Window Hinges

Name: Stainless Steel Square Window Accessories Friction Stay Upvc Window Hinges
Brand: Sincego
SKU: 127591855
Availability: InStock

US$ 0.5 - 2 MOQ: 500 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Sincego

Model Number:

FSH1800-LR2

Zhaoqing City Gaoyao Area Jinli Xi Da Hardware Product Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Sincego

Model Number FSH1800-LR2

Stainless steel square window accessories friction stay upvc window hinges

Product Description

Material:iron steel,zinc plated surface.

Bar thickness:.3mm
Track width:22mm
Factory will serve you wholeheartedly.

Material:iron steel
zinc plated surface
Be suitalbe for UPVC windows and ventilators.
Operates normally after 30000 times strict opened/closed.
It provides adequate friction at all opening angles.
Available for left and right hands.
All friction stays are tested to rigorous salt-pray test for protection against corrosive atmospheres.
Fine workmanship .Easy to install.
Reliability is our strong point..
The products are conformes to national technical standard QB/T3888-1999 for <Aluminum Alloy Stainless Steel Window Hinge>.

Specification	Length	L1	L2	L3	L4	Track Width	Arm Width	Max Vent Height	Max Vent Width	Max Vent Weight	Supportive suspension Bar thickness	Stack Height	Opening Angle
10#	255	28	183	41	158	22	18	1000	1000	16	2.0 ±0.2	15 ±0 .5	88°±1°
12#	295	30	180	86	169	22	18	1100	1100	19	2.5 ±0.2	15 ±0 .5	88°±1°
14#	340	29	218	90	210	22	18	1150	1150	22	2.5 ±0 .2	15 ±0 .5	88°±1°
16#	400	32	209	154	200	22	18	1200	800	25	2.5±0 .2	15 ±0 .5	88°±1°
18#	450	29	197	217	200	22	18	1200	850	28	2.5±0 .2	15 ±0 .5	88°±1°
