FR core fire resistant PE PVDF aluminum composite panel
We are one of preferred quality suppliers in ACP industry.
A. Inherent Advantages in Cost
1, We are the only aluminum composite panel manfacturer located in the east of Guangdong. Labor cost is way much lower than those of other location of Guangdong,Zhejiang,Jiangsu,Shandong,etc.
2, We own a PE(ACP core) factory which allows us to avoid buying PE raw material from suppliers in market. We save cost for customers.
B. Excellent Quality
Over 80% of engineers have been working in our factory for more than 9 years. With their professional knowledge and experience,we have been supplying excellent quality aluminum composite panel to customers in and abroad.
C. Professional Service Team
Your perception is our reality. A smooth process and strong finish is our aim on every project. Not only do we have the resources to meet the challenges of each project, we take great care in how our work is executed. Everyone of our service team is specialist in this business. They can help you with any questions related to ACP such as difference of material,prices,shipping,customs clearance,etc. You can reach our 24/7 service team at +86-159 9256 3464 (Wechat/Whats app)
A. Specifications and Sizes
| Dimensions | Tolerance |
| 1, Thickness: 1mm,2mm,3mm,4mm,5mm,6mm | ± 0.04 |
| 2, Skin Thickness:0.05-0.5mm | ± 0.01 |
| 3, Width: 1220mm-2000mm | ± 2 |
| 4, Length: 800mm-6500mm | ± 3 |
| 5, Standard size:1220mm*2440mm | |
| 6, Total thickness: 2-4mm for indoor decoration | |
| 7, Total thickness: 4-6mm for outdoor decoration | |
| 8, Colors: Customized | |
| 9, Special size: available | |
| (Size can be customized according to the designs of curtain walls.) |
B. Product Info
| FR core fire resistant PE PVDF aluminum composite panel | |
| 1, Product: Fire resistant Aluminum-plastic Composite Panel | |
| 2, Surface Coating:PVDF(Anodized,Brushed,Foil Decoration,Mirror,PE,Printing) | |
| 3, Standard:according to GB/T 17748-2008 | |
| 4, Certificates:ISO,SGS,BV,CE,CQC,IAF | |
| 5, OEM accepted | |
| 6, Guarantee for 25 years(PVDF) | |
| 7, 9 years production history | |
| 8, MOQ:600 square meters |
C. Core Quality
| Top quality FR core | |
| Remark: | |
| 1) We use the highest quality raw material to make the fire-resistant core; | |
| 2) Raw fire resistant material tested before injection; | |
| 3) Final products go through strict tests. |
D. Features
| 1, Well weather-resistance, high rigidity, easy for maintenance, only neutral cleanser and water needed for its self-clean performance; | |
| 2, Easy finishing with conventional woodworking tools. Short time needs for project; | |
| 3, Good workability, fire-resistant, heat & sound insulation; | |
| 4, High flexibility and impact-resistance, superior surface flatness, lightweight, rigid; | |
| 5, Various colours are available to meet your needs; | |
| 6, Competitive price,excellent quality and quick delivery; | |
| 7, Project scope of application decoration of both interior and exterior walls of large-scale modernized constructions, outdoor billboards, signs, large-scale exposition booth construction, building renovation, etc. |
E. Fire Test
Our in-house testing capabilities allow us to go beyond the standare methods and evaluate real world conditions.
Click below links to browse our product categories
1, Pearl Series aluminum composite panel
2, Mirror-surface aluminum composite panel
3, Brushed aluminum composite panel
4, Marble/Granite aluminum composite panel
5, Light aluminum composite panel
6, PE/PVDF aluminum composite panel
PHYSICAL PROPERTIES
| Properties | 2 mm | 3 mm | 4 mm | 6 mm |
| Aluminum thickness, in (mm) | 0.010 (0.25) | 0.010 (0.25) | 0.020 (0.5) | 0.020 (0.5) |
| Weight, psf (kg/m2) | 0.59 (2.9) | 0.80 (3.9) | 1.12 (5.5) | 1.50 (7.32) |
| Coefficient of expansion, ASTM D696, in/in/°F | 13 × 10^-6 | 13 × 10^-6 | 13 × 10^-6 | 13 × 10^-6 |
| Tensile strength, ASTM E8, psi (MPa) | - | - | 6913 (48) | 4978 (35) |
| Yield strength, ASTM E8, psi (MPa) | - | - | 6429 (44) | 4466 (30) |
| Elongation | - | - | 13.50% | 17.50% |
| Thermal conductance, ASTM C976, Btu/(ft2 × h × °F) (W/(m2 × K)) | - | - | 10.75 (18) | 8.53 (14) |
| Minimum Drum peel, ASTM D1781, in-lb/in(N-mm/mm) | - | - | 22.5 (100) | 22.5 (100) |
| Thermal resistance, ft2 × h × °F/Btu (m2 × K/W) | - | - | 0.09 (0.016) | 0.12 (0.021) |
| Sound transmission coefficient, ASTM E413 | - | - | 26 | 26 |
FIRE PERFORMANCE PROPERTIES
| Properties | 4 mm | 6 mm | ||
| Surface burning characteristics, ASTM E84 | ||||
| Smoke developed index | 450 maximum | 450 maximum | ||
| Flamespread index | 25 maximum | 25 maximum | ||
| Vertical transmission, ASTM E108 (modified) | Passed | Passed | ||
| Ignition temperature, ASTM D1929 | ||||
| Flash ignition | 716° F (380° C) | - | ||
| Self-ignition | 752° F (400° C) | - | ||
| Rate of burning, ASTM D635 | CCI | - | ||
