Vacuum evaporator 50L Borosilicate Condenser Explosion (Flame) Proof

Specifications

Vacuum evaporator can perform condensation, distillation and menstruum recycle under negative pressure and constant pressure.

Description:

Vacuum evaporator can form film to perform condensation, distillation and menstruum recycle under negative pressure and constant temperature. Rotary evaporator is especially applied in condensing, crystallizing and separating heat-sensitive material and recycling menstruum. Moreover, new functions of reflux extraction are added to new model of our products.



Features:

1. Efficient Integrated Tandem Dual Reflux Condenser (1.65 sqm condensing area);

2. Automatic bath lifting system, stable and safe;

3. Flask holding system ensuring easy and safe removal;

4. Ceramic Mechanical/PTFE seal assemble with excellent airproof and resistant to erosion;

5. Glass duct prevents material from reaching metallicity and pollution;

6. Modular design with high compatibility and easy maintenance;

7. G3.3 Pyrex Glass (Borosilicate) with good physical and chemical properties;

8. Frequency Conversion speed adjustment;

9. Stainless-steel head of motor, resistance to erosion and easy to unload;

10. Twin receiving flasks with balanced converter switch perform continuous discharge of material;

11. Big mouth rotary flask, easy for wash and operation;

12. PTFE Bottom Discharge Valve, No Grease pollution;

13. Epoxy Painting for Anti-Erosion Structure is optional;

14. Explosion Proof (Flame Proof) devices are optional.



Technical Information:

Model	R5002B
Rotary Flask (L)	50L/F125#
Receiving Flask (L)	20L + 10L Bottom Discharge
Condenser Type & Area (sqm)	Integrated Tandem Dual Reflux (1.65)
Evaporation Efficiency (H2O)	> 9.0L/h
Motor Power (w)	250 w
Rotary Speed (rpm)	10 - 110
Display Type Of Rotary Speed	Digital
Seal Type	Ceramic Mechanical/PTFE Seal Assemble (Teflon)
Reachable Vacuum Level (Mpa)	<-0.098Mpa
Vacuum Meter	Needle
Speed Adjustment	Frequency Conversion
Glassware Material	Borosilicate (Pyrex: G3.3)
Bath Type	Internal Heating
Bath Power (kw)	6 kw
Temperature Range Of Bath (°C)	Room Temperature - 180°C
Lift Type	Automatic Lifting Of Bath
Lift Distance (cm)	18cm
Bath Material	SUS304
Dimensions Of Bath (cm)	55x35
Dimensions (cm)	130x80x230
Power	380V/220V/5A
Extra Component (Optional)	Epoxy Painting
Extra Component II (Optional)	Explosion Proof



Picture:



Explosion Proof (Flame Proof) Technical Information:

BXM(D) Serial Explosion Proof Distribution Box
Explosion Proof Mark	EXdeIIBT6, ExdellCT6
Rated Voltage	AC380V/220V/50Hz
Main Reflux Rated Voltage	60A-250A
Protection Level	IP54, IP55
Anti-erosion Level	WF1

1. Aluminum alloyed shell with polyester powder painted on surface by high voltage static electricity;

2. In-built high rupture circuit breaker and Frequency converter;

3. Modular Design for customized need on circuits (Flameproof Structure of Switch Box, Increased Safety Type of Bus-bar Chamber and Terminal Box);

4. Protection from overload or short-circuit.



For details, please contact us. Based on your needs, we will customize Rotary Evaporator, equipped with vacuum pump, cooling system and control system.
