Multiple Effect Evaporator 30L Borosilicate Condenser Explosion (Flame) Proof

Multiple Effect Evaporator 30L Borosilicate Condenser Explosion (Flame) Proof thumbnail-1
Multiple Effect Evaporator 30L Borosilicate Condenser Explosion (Flame) Proof photo-1
US$ 6,300 - 6,400 MOQ: 1 Set
Key Specifications
Get Latest Price
Application:
Pharmaceutical Processing
Power Source:
Electric
Process:
Rotary
Contact Supplier Request Quote Chat Now
Shanghai Shensheng Biotech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Application Pharmaceutical Processing
Power Source Electric
Process Rotary
Place of Origin Shanghai, China
Brand Name Shensheng
Model Number R3002B

Specifications

Multiple effect evaporator perform condensation, distillation and menstruum recycle under negative pressure and constant press

Description:

Multiple effect evaporator can form film to perform condensation, distillation and menstruum recycle under negative pressure and constant temperature. Rotary evaporator is especially applied in condensing, crystallizing and separating heat-sensitive material and recycling menstruum. Moreover, new functions of reflux extraction are added to new model of our products.



Features:

1. Efficient Integrated Tandem Dual Reflux Condenser (1.28 sqm condensing area);

2. Automatic bath lifting system, stable and safe;

3. Flask holding system ensuring easy and safe removal;

4. Ceramic Mechanical/PTFE seal assemble with excellent airproof and resistant to erosion;

5. Glass duct prevents material from reaching metallicity and pollution;

6. Modular design with high compatibility and easy maintenance;

7. G3.3 Pyrex Glass (Borosilicate) with good physical and chemical properties;

8. Frequency Conversion speed adjustment;

9. Stainless-steel head of motor, resistance to erosion and easy to unload;

10. Twin receiving flasks with balanced converter switch perform continuous discharge of material;

11. Big mouth rotary flask, easy for wash and operation;

12. PTFE Bottom Discharge Valve, No Grease pollution;

13. Epoxy Painting for Anti-Erosion Structure is optional;

14. Explosion Proof (Flame Proof) devices are optional.





Technical Information:



Model R3002B
Rotary Flask (L) 30L/F125#
Receiving Flask (L) 10L + 5L Bottom Discharge
Condenser Type & Area (sqm) Integrated Tandem Dual Reflux (1.28)
Evaporation Efficiency (H2O) > 6.5L/h
Motor Power (w) 250 w
Rotary Speed (rpm) 10 - 110
Display Type Of Rotary Speed Digital
Seal Type Ceramic Mechanical/PTFE Seal Assemble (Teflon)
Reachable Vacuum Level (Mpa) 0.098Mpa
Vacuum Meter Needle
Speed Adjustment Frequency Conversion
Glassware Material Borosilicate (Pyrex: G3.3)
Bath Type Internal Heating
Bath Power (kw) 4 kw
Temperature Range Of Bath (°C) Room Temperature - 180°C
Lift Type Automatic Lifting Of Bath
Lift Distance (cm) 18cm
Bath Material SUS304
Dimensions Of Bath (cm) 50x27
Dimensions (cm) 120x75x210
Power 380V/220V/5A
Extra Component (Optional) Epoxy Painting
Extra Component II (Optional) Explosion Proof



Picture:

Multiple effect evaporator 30L Borosilicate Condenser Explosion (Flame) Proof



Parameter of Glassware:

                          Borosilicate  (Pyrex: G3.3)
Chemical Composition (Weight%) SiO2        80.7
B2O5        12.8
Al2O3         2.2
CaO       <0.6
K2O
Na2O		         4.0
Parameters

Linear  Expansivity

  a≤32*10^(-7)

Thermal Shock Resistance (°C)

        270
Softening (°C)        820
Anneal (°C)        565

Highest Temperature (°C)

Continuous Use (°C)

        510



Explosion Proof (Flame Proof) Technical Information:

BXM(D) Serial Explosion Proof Distribution Box
Explosion Proof Mark  EXdeIIBT6, ExdellCT6
Rated Voltage  AC380V/220V/50Hz
Main Reflux Rated Voltage 60A-250A
Protection Level IP54, IP55
Anti-erosion Level WF1

1. Aluminum alloyed shell with polyester powder painted on surface by high voltage static electricity;

2. In-built high rupture circuit breaker and Frequency converter;

3. Modular Design for customized need on circuits (Flameproof Structure of Switch Box, Increased Safety Type of Bus-bar Chamber and Terminal Box);

4. Protection from overload or short-circuit.



For details, please contact us. Based on your needs, we will customize Rotary Evaporator, equipped with vacuum pump, cooling system and control system.
