Single Effect Evaporator 2L With Auto Lifting & Vertical Condenser

Specifications

Single effect evaporator perform condensation, distillation and menstruum recycle under negative pressure and constant pressure

Description:

Single effect evaporator can form film to perform condensation, distillation and menstruum recycle under negative pressure and constant temperature. Rotary evaporator is especially applied in condensing, crystallizing and separating heat-sensitive material and recycling menstruum. Moreover, new functions of reflux extraction are added to new model of our products.



Features:

1. Automatic motor lifting system;

2. External-heating bath, no heating ring, easy-maintenance, user-friendly;

3. AC Induction Motor with Stepless speed regulation, no dynamo brush, spark-free;

4. Efficient Dual-reflux Vertical Condenser (0.16sqm condensing area);

5. Glass duct prevents material from reaching metallicity and pollution;

6. PTFE seal assemble  (Teflon) with resistance to erosion;

7. Stainless-steel head of motor, resistance to erosion and easy to unload;

8. Connector for Anti-backflow of Condensate;

9. PTFE Bottom Discharge Valve, No Grease pollution;

10. Epoxy Painting for Anti-Erosion Structure is optional.



Technical Information:

Model	R209B
Rotary Flask (ml)	500ml/29# +1000ml/29#
Receiving Flask (ml)	1000ml/35#
Condenser Type & Area (sqm)	Dual-reflux Vertical (0.16)
Evaporation Efficiency (H2O)	> 1.2L/h
Motor Power (w)	40 w
Rotary Speed (rpm)	50 - 180
Display Type Of Rotary Speed	Digital
Seal Type	PTFE Seal Assemble (Teflon)
Reachable Vacuum Level (Mpa)	<-0.098Mpa
Vacuum Meter	Needle
Speed Adjustment	Electronic Stepless
Glassware Material	Borosilicate (Pyrex: G3.3)
Bath Type	External Heating
Bath Power (kw)	1.1 kw
Temperature Range Of Bath (°C)	Room Temperature - 180°C
Lift Type	Automatic Lifting Of Motor
Lift Distance (cm)	11cm
Bath Material	SUS304
Dimensions Of Bath (cm)	24x15
Dimensions (cm)	70x50x70
Power	220V/5A
Extra Component (Optional)	Epoxy Painting



Parameter of Glassware:

Borosilicate  (Pyrex: G3.3)
Chemical Composition (Weight%)	SiO2	80.7
	B2O5	12.8
	Al2O3	2.2
	CaO	<0.6
	K2O           Na2O	4.0
Parameters	Linear       Expansivity	a<32*10^(-7)
	Thermal Shock  Resistance (°C)	270
	Softening (°C)	820
	Anneal (°C)	565
Highest Temperature (°C)	Continuous Use (°C)	510



For details, please contact us. Based on your needs, we will customize Rotary Evaporator, equipped with vacuum pump, cooling system and control system.
