Eric ERT-100T Satellite Optical Transmitter
Product Features
1) Supports LNB feeding optical and 22khz 13/18V DC
2) Different wavelengths and input range selectable on demand
3) Switching AGC
Specification
Downstream signal path | |
Optical wavelength |
1310 nm FP laser |
Optical Output power of 1 |
1 mW Typical |
Optical Output power of 2 |
1 mW Typical |
Frequency range |
45/950…2600 MHz |
Entry level |
55-78dBµV |
LNB Power |
13V and 18V |
RF Return Loss |
13 |
Input impedance |
75Ω |
CNR |
40dB |
IMD |
40dB |
General | |
Power consumption |
3.5W |
Power supply |
18V DC |
RF connectors |
F female |
Optical connector(s) |
SC/APC |
Dimensions (H x W x D) |
118 mm x 210 mm x 40 mm |
Weight |
0.25 kg |
Contact us
We highly appreciate your any enquiry by email, or instant message ,
We will reply your email within 12 hours .
please feel free to call us at any time if there is any questions.
Transportation
All available shipping ways could be applied. by express,air .
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the items for you before the goods arrive .
Our Services
1.Any inquiries will be replied within 24hours
2.Professional manufacturer.
3.OEM/ODM avaliable:
1)Silk print logo on the front panel
2)Customized Color box
3)Customized housing
4)Any your idea on our equipments we can help you to design and put it into production
4.High quality, fashion designs, reasonable and competitive price, fast lead time
5.After-sale service:
1)All products will have been strictly quality checked in house before packing
2)All products will be well packed before shipping
3)All our products have 1year warranty.
6.Faster delivery:
Sample order 1~3working days, and 3~7 working days for bulk production
7:Payment:
You can pay fro the order via: T/T,Western Union, Paypal and others, or place order directly on Aliexpress
8.Shipping:
We have strong cooperation with DHL, TNT,UPS,FEDEX,EMS and China Air Post
You also can choose your own shipping forwarder.
Certificates
Our Factory
About us
We are manufacturer of all CATV optical equipments such as FTTH optical receivers, Optical transmitters, Optical amplifier-EDFA , SAT-IF optical transmitters and receivers, Optic Transceiver Module and Optical Fiber Test instruments.
If you need optical equipments,please contact with me without hesitation!
