Honda Original Gasoline Engine GX160/Honda GX160 Engine 5.5HP

Name: Honda Original Gasoline Engine GX160/Honda GX160 Engine 5.5HP
Brand: HONDA OR OEM
Availability: InStock

FOB Price

US$ 150 - 200 / Set

10 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Usage	Automobile
Fuel	Gasoline	Stroke	4 Stroke
Cylinder	Single Cylinder	Cold Style	Other, Air-cooled
Start	Kick Start	Place of Origin	Jiangsu, China
Brand Name	HONDA OR OEM	Model Number	GX160
Dimension(LWH)	387330360	Weight	15KGS
Certification	CE,EPA,CARB	Warranty	24 months
After-sales Service Provided	Engineers available to service machinery overseas

Model	GX160	GX200	GX390
Engine Type	Air-cooled 4-stroke OHV	Air-cooled 4-stroke OHV	Air-cooled 4-stroke OHV
Bore x Stroke	68 X 45 mm	68 X 54 mm	88 X 64 mm
Displacement	163 cm3	196 cm3	389 cm3
Net Power Output*	4.8 HP (3.6 kW) @ 3,600 rpm	5.5 HP (4.1 kW) @ 3,600 rpm	11.7 HP (8.7 kW) @ 3,600 rpm
Net Torque	7.6 lb-ft (10.3 Nm) @ 2,500 rpm	9.1 lb-ft (12.4 Nm) @ 2,500 rpm	19.5 lb-ft (26.4 Nm) @ 2,500 rpm
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)	Counterclockwise (from PTO shaft side)	Counterclockwise (from PTO shaft side)
Compression Ratio	9.0 : 1	8.5:1	8.2:1
Lamp/Charge coil options	25W, 50W / 1A, 3A, 7A	25W, 50W / 1A, 3A, 7A	25W, 50W / 1A, 3A, 10A, 18A
Carburetor	Butterfly	Butterfly	Butterfly Float Type
Ignition System	Transistorized magneto	Transistorized magneto	Digital CDI with variable timing
Starting System	Recoil Starter	Recoil Starter	Recoil/electric
Lubrication System	Splash	Splash	Splash
Governor System	Centrifugal Mechanical	Mechanical	Centrifugal Mass Type
Air cleaner	Dual Element	Dual element	Dual element
Oil Capacity	0.61 US qt. (0.58 L)	0.63 US qt (0.6l)	1.16 US qt (1.1 L)
Fuel Tank Capacity	3.3 U.S. qts (3.1 liters)	3.3 U.S. qts (3.1 liters)	6.4 U.S. qts (6.1 liters)
Fuel	Unleaded 86 octane or higher	Unleaded 86 octane or higher	Unleaded 86 octane or higher
Dry Weight	33 lbs. (15.1 kg)	35 lbs. (16.1 kg)	69 lb (31.5 kg)
