Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > 10/100M 4 Ports Media Converter

10/100M 4 Ports Media Converter

Name: 10/100M 4 Ports Media Converter
Brand: Eric
SKU: 127571361
Availability: InStock

10/100M 4 Ports Media Converter thumbnail-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Eric

Model Number:

ER-SF05M

Contact Supplier Request Quote Chat Now

Hangzhou Eric Communication Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai /shenzhen /ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Eric

Model Number ER-SF05M

Specifications

1.10/100M 4 ports media converter
2.Supporting the max 1916 bytes frame
3.Broadcast storm protection
4.Fiber: ST/SC/FC,100Mbp

10/100M 4 ports media converter

Description

There are one 100M optical fiber port and three 10/100M UTP ports. The product is possessed of stable performance, excellent quality and reasonable price because of adopting latest IC from USA and high quality of transceivers. It is applicable to use in small patterns of Optical Fiber Ethernet.

Main Feature

1.It can convert Optical-Electric Ethernet signals between 10/100M UTP ports (TX) and 100M optical fiber interface (FX).

2.UTP port supports MDI / MDI-X auto crossover

3.Broadcast storm protection

4.Supporting the max 1916 bytes

Technical Specification

1.Operating standards: IEEE802.3u 100Base-TX and 100Base-FX

2.Connector: UTP: RJ-45,10/100Mbps; Fiber: ST/SC/FC,100Mbps (Full Duplex)

3.Cable

UTP cable: Cat. 5 (the max distance up to 100m)

Fiber (multimode): 50/125, 62.5/125μm(the max distance up to 2km)

Fiber (singlemode): 8.3/125, 8.7/125, 9/125, 10/125μm (the max distance up to 100km)

4.Flow control

Full Duplex: IEEE802.3x flow control

Half Duplex: bake pressure flow control

5.Power supply: AC110 ~ 240V

6.Environment temperature:0 ~ +50°C

7.Storage temperature:::-20 ~ +70°C

8.Humidity::5% ~ 90%

9.Dimensions:180 × 45 × 143mm

Order Information

Model	Connector	Fiber type	Max distance	Wavelength	TX power	Sensitivity	Link Budget
ER-SF05M	SC/ST	multimode	2km	850 or 1310nm	-20~-12dBm	-30dBm	10dBm
ER-SF05S	SC	singlemode	20km	1310nm	-14~-8dBm	-32dBm	18dBm

Model	Product description
ER-SF05M	10/100M Ethernet Multimode Fiber Switch with 3 UTP ports and 1 multimode fiber port, 850 or 1310nm of optical wavelength, the max distance of fiber up to 2km.
ER-SF05S	10/100M Ethernet Singlemode Fiber Switch with 3 UTP ports and 1 singlemode fiber port, 1310 or 1550nm of optical wavelength, the max distance of fiber up to 20~100km.
