Home > Products > Agricultural Machinery > Diesel Walking Tractor With Plough/walking Behind Tractor/diesel Power Tiller
Diesel Walking Tractor With Plough/walking Behind Tractor/diesel Power Tiller
US$ 800 - 1,000
/ Set
5 Sets(Min. Order)
- shanghai
- T/T D/P D/A Money Gram
You May Like
-
Agriculture Power Sprayer/gasoline Engine Power Sprayer/sprayer Machine
-
Power Sprayer/portable Power Sprayer/agriculture Power Sprayer/gasoline and Diesel Power Sprayer
-
Plate Compactor C90,mini Plate Compactor.robin Plate Compactor
-
Robin Concrete Vibrator,construction Vibrator,concrete Vibrating Screed
-
Bidirectional Plate Compactor Powered by Diesel Enigne 178F
-
Pavement Rammer
Product Details
| Condition | New | Type | Walking Tractor | |
| By wheel | 2WD | Usage | Farm Tractor | |
| Drive Type | Gear Drive | Power(W) | dongfeng 12 | |
| Certificate | Other, iso | Brand Name | JD or OEM | |
| Model Number | DF-18L | Place of Origin | Jiangsu, China | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Product Description
| Model of Power Tiller | Unit | FSH-18D | FSH-20D | |
| Structure weight | Without rotavator | kg | 520 | 530 |
| With rotavator | 645 | 655 | ||
| Working weight (with rotavator) | kg | 680 | 695 | |
| Turning speed of rototilling shaft | rpm | 188/300 | ||
| Overall dimensions (LxWxH) | mm | 2680 x 1030 x 1250 | ||
| Number of blades | PCS | 24 | ||
| Rototilling width | mm | 800/900 | ||
| Type of tractor | Single axle, dual-purpose for both traction & drive | |||
| Travelling speed | Forword | Km/h | 1.4,2.5,4.1,5.3,9.4,15.3 | |
| Reverse | 1.1, 3.8 | |||
| Type size | 6.00-12 | |||
| Wheel track | mm | 800, 740, 640, 580(normally use 800) | ||
| Min. ground clearance | mm | 185 | ||
| Min. turning radius | m | 0.9(with no rotavator) | ||
| Model of engine | ZS1105N | ZS1110N | ||
| Type of engine | Horizontal 4-stroke | |||
| Bore x stroke | mm | 105×115 | 110×115 | |
| Total displacement | L | 0.9959 | 1.0931 | |
| Compression ratio | 17:01 | |||
| Turing speed of crankshaft | rpm | 2200 | ||
| 1-hour rated output | KW/hphp | 13.34/18.15 | 14.7/20 | |
| 12-hour rated output | KW/hp | 12.13/16.5 | 13.23/18 | |
| Specific fuel consumption | g/kw.h | ≤246.2 | ≤244.8 | |
| Specific lube oil consumption | g/kw.h | ≤2.00 | ≤1.47 | |
| Cooling mode | Condenser (Radiator) | |||
| Main farm implements (optional) | Anti-skid steel wheel Model 100-640 | |||
| Double-furrow plough Model 1LS-220 | ||||
| Disk plough Model 1LS-220Y | ||||
| Power driven disk plough Model 1LYQ-320 | ||||
| Sprinkler Model 8Y-80 | ||||
| Swather/reaper Model 4GL-130 | ||||
| Trailer 7C-1.5 (Standard) | ||||
| Trailer 7C-1.5BH (Hydraulic dumping) | ||||
