horizontal flow wrapping machine for wafer bar SZ-400
- 50 Set / Sets per Month
- Foshan
- T/T Credit Card PayPal
- Without electricity waste tire doubling and tripling machine scrap tyre packing unpacking machine
- MK60S Semi Automatic Strapping Machine
- Mastek Strapping Head
- MK900 Fully Automatic Strapping & Wrapping All In One Machine
- Chocolate Candy Foil Folding Wrapping Machine
- chicken/bouillon cube Wrapping machinery /cube packaging machinery
Product Details
Condition: | New | Application: | Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical | Packaging Type: | Bags, Capsule, Film, Foil, Pouch, Stand-up Pouch |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V | Power: | 2.6KW | Place of Origin: | Guangdong, China |
Brand Name: | SUK | Model Number: | SZ-400 | Dimension(L*W*H): | (L)4020*(W)800*(H)1450mm |
Weight: | 900KG | Certification: | CE | After-sales Service Provided: | Overseas service center available |
Product Description
Horizontal flow wrapping machine for wafer bar SZ-400
Main performance & structure characteristics
1. Double converters control bag length which can be set and cut. There is no need to adjust empty which will be prompted automatically by the humanized operation, saving time and membrane.
2. Master control circuit adopts imported single-chip microcomputer with man-machine interface and frequency control, making setting parameters convenient and quick and operation intuitive.Fully implement the humanized automatic operation.
3. Digital fault self-diagnosis function.Fault diagnosis is clear at a glance
4. Packing speed and bag length adopts dual frequency conversion control, digital sealing and cutting position input. The sealing and cutting position is precise, beautiful and solid.
5. Highly sensitive photoelectric device tracks automatically and accurately.
6. Positioning stop function without sticking knife, cutting and wasting envelope.
7.Double frequency contracted mechanical structure with less worn, easy maintenance and long life.
8. The temperature of each seal is independent. PID control is suitable to various packaging materials.
9. All controls are implemented by software. It can install intermittent air device and spray alcohol device to implement adjusting functions immediately and upgrading technology to ensure it will never fall behind.
Applications
Be applicable for packaging of solid and regular products like biscuit, moon cake, candy, insulating tape, wet tissues, paper tissues, cartoon, mosquito-repellent incense and Chinese date.
Technical parameters
Type | SZ-400B | SZ-400D |
Film width | Max.400mm | |
Bag length | 130-320mm | 180-400mm |
Bag width | 50-185mm | |
Product height | Max.40mm | Max.60mm |
Film roll diameter | Max.320mm | |
Packaging rate | 30-180bag/min | |
Power | 220v 50/60Hz 2.6KW | |
Machine size | (L)4020×(W)800×(H)1450mm | |
Machine weight | 900KG | |
Remarks | Optional air filling device |
