Product Details
Condition: | New | Application: | Beverage, Chemical, Commodity, Food | Packaging Type: | Case, Film, Foil, Pouch |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V | Power: | 2.2KV | Place of Origin: | Guangdong, China |
Brand Name: | SUK | Model Number: | CYL-60L | Dimension(L*W*H): | (L)2860 * (W)680 *( H)1650mm |
Weight: | 350KG | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
pecifications
1.Full automatic
2.CE certificate
3.Panasonic PLC control
4.High configuration and Low consumption
Automatic liquid packaging machine
Features:
1.Mitsubishi programmable logic controller (PLC) with Chinese and English human computer interface, simply operation and easy adjustment, highly automaticity.
2.Intelligent temperature controller with two-way (horizontal & vertical) control, sealing good and fastness, smooth form and fineness.
3.Adopt stepping motor control, auto tracking and fixed position, smooth working, lower noise.
4.Intelligent photoelectric tracking system and automatic compensation to confirm packing bag aligned front and back, highly efficiency.
5.Step less speed regulating in rated range, positioning mouth shut down is workable.
6.Fully automatically complete all packaging step (bag-making, measuring, filling, sealing, cutting, date printing).
Configuration:
1. Host machine
2. Pump
3. Products conveyor
Option:
1.Two synchronous belt device
2.angle fold device
3.automatic rectifying device
4.hole-punching device
bag device
Applications:
Suitable for general form, semi-viscous form, highly viscous liquid materials such as shampoo, facial cream, oil, sauce, jam, etc.
Specification:
Model | CLY-60L |
Film width | 40~140mm |
Film roll diameter | Max. 300mm |
Packaging speed | 35~100bag/min |
Bag size | L:40~160mm W:40~100mm |
Measuring range | 1~100ml |
Power | 220V 50Hz 2Kw |
Size (mm) | (L)2860 * (W)680 *( H)1650 |
Net weight | 300kg |
Packing material | BOPP/CPP, BOPP/PE, PET/AL/PE, NY/PE, PAPER, TEA FILTER PAPER, PLA, NON-WOVEN FABRICS |
Main picture of Petroleum jelly liquid packing machine CYL-60L
Sample of Packing bag
Packing products
Quality guarantee:
1. Each machine is manufactured by our professional workers.
2. Each machine with a strict inspection before out of storage.
3. Each machine use a large number of 304 stainless steel.
4. Each machine use good quality electric elements.
5. After-sales service commitment: after one month, 3 months... we will have return visiting by phone or mail.
6. The warranty time is one year.
Within Warranty period, if under the usage of instruction sheet, any product broken or damage, we will offer the repair service for free or replace for free, but clients pay for the freight from China to local place. If need our engineer go to help, clients need to pay for the freight of round-trip.
7. Beside the warranty days, we continue to provide life-long maintenance services.
Terms:
1. Original: made in China
2. Package: wooden case.
3. Loading port: Foshan
4. Payment terms: 30% deposit with the order, 70% balance before shipment.
5. Delivery time:35 days after receiving deposit and samples
6. Guarantee: 1 year
7. Installation: We can send one technician to buyer's factory to install machine and train their worker. The buyer has to pay USD80 per day for the technician as subsidy. All the expense, such as visa, round trip tickets, and accommodation should be born by buyer.
8. Remark: If you have special demand of some parts like motor, cylinder, control panel, filling, material, conveyor, collect table, plexiglass cover and others, please tell us.
