Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > Super Mini Network Camera
US$ 59 - 77
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
VStarcam
Model Number:
C7812IP
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Viewerframe Mode Network ip Camera Took off Cmos Cctv Hisilicon WIFI Wireless 720p ip Cctv CamerasUS$ 55 - 85MOQ: 50 Pieces -
Vstarcam Took off Cmos Cctv Hisilicon WIFI Wireless 720p ip Cctv CamerasUS$ 55 - 85MOQ: 50 Pieces
-
Hot New Products Plug Play WIP Wireless Megapixel Hisilicon ip Camera Wireless Ip Camera WIFI Wireless IP CameraUS$ 55 - 85MOQ: 50 Pieces
-
Home Security and Surveillance Wireless ip IP Webcam ip Cctv Camera Wifi Camera Security PNPUS$ 55 - 85MOQ: 50 Pieces
-
New H.264 PnP HD Home Security Camera Wired ip Dome CameraUS$ 50 - 60MOQ: 2 Pieces
Place of Origin
Guangdong, China
Brand Name
VStarcam
Model Number
C7812IP
Type
Other, Digital Camera, onvif ip camera
Style
Dome Camera
Sensor
CMOS
Technology
NetWork
Special Features
Waterproof / Weatherproof
Super mini network camera
Product Description
| Model :C7821IP | ||
| Features | System security | Account, password authority management |
| Free DDNS | Free DDNS, supports dynamic IP. | |
| View by phone | Support HD pic IOS, Android mobile view (iOS 4.3,Android OS 2.3 above) | |
| Local Storage | support up to 32GB MicroSD card ,24-hour loop recording. | |
| Monitor Advantage | Support PC computer monitoring, smartphone multi-pic view. | |
| PnP | Plug & Play,99% penetration rate, Easy to setup: 1. connect the network cable and power adapter, 2.install APP, scan UID code to add camera. 3,Click online camera to view the camera. | |
| Sever cluster | Using Amazon Cloud PnP servier cluster, intelligent application and super stable | |
| UID Technology | UID scan technology applied, easy to operate, and highly confidential. | |
| Super Client | 1,4,9,16,25,36, 64,81-channel central management software, no user number limitation , centralized surveillance, remote record and playback, alarm email ect. | |
| System | OS | Embedded Linux OS |
| Control protocol | ONVIF 2.0 protocol, high interoperability | |
| Video coding | Multi stream:720P@30fps+VGA@30fps+QVGA@30fps+720P @1fsJPEG capture | |
| Bit Rate | CBR/VBR, output bit rate range:128~4096kbps | |
| Processor | Hi processor, built in ARM926 @Max. 440MHz and high-speed video co-processor | |
| Video | Compression Format | H.264 baseline profile@levels:3.1/Motion-JPEG |
| Frame rate | 30fps/24fps(720p) | |
| Resolution | 720P(1280*720), VGA(640*480), QVGA(320*240) | |
| Picture Adjustment | Contrast, Brightness, Saturation are adjustable. | |
| Sensor | 1/4 720p Progressive CMOS sensor | |
| Minimum illumination | 0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode) | |
| SNR | ≥39dB | |
| IR control | IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode. | |
| Electronic shutter | 1/50s(1/60s)-1/100, 000s | |
| CMOS | support AWB, AGC, BLC | |
| Lens/viewing angle | 3.6mm @F1.4/56.14° | |
| Night Vision | Night vision | Dual IR-CUT Filter auto switch, 12pcs 850nmΦ5mm LED,10m IR distance |
| Audio | Compression format | ADPCM/32kbps |
| Input | 1 Channel Line in (3.5mm phone jack) &1 Channel Internal -48dB Microphone | |
| Output | 1 Channel Line out (3.5mm phone jack)&Internal speaker(8Ω1W) | |
| P/T | P/T | Pan:355°,Tilt:120° |
| Preset Postion | suppor up to 15 preset postions | |
| Network | network interface | 10Base-T/100Base-TX Ethernet interface |
| Network Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,etc. | |
| wireless network security | WPS encryption | |
| Online visitor | Support 4 online visitors simutaneoursly | |
| IP address | Dynamic IP and static IP address | |
| WIFI | WIFI 802.11 b/g/n | |
| Others | housing material | engineering plastics |
| Application environment | Indoor | |
| Rated Voltage | DC5±0.3V | |
| Temperature | -10~50 °C | |
| Power consumption | rated power:3.5W(IR opening )/maximum power:7W(P/T working ) | |
| Package size | 195x140x130mm (L×W×H) | |
| Weight | Gross Weight :755g(Note: in kind prevail) | |
| Accessories | Power adapter, user manual, warranty card, mounting bracket, screws. | |
| Alarm | Motion Detection | Support motion detecting |
| System Requirement | System configuration | Win98 SE/ME/2000/XP,Vista,iPhone iOS4.3,The android version 2.3 or higher |
| Certificate | Certificate | ISO FCC CE RoHS |
| Only for reference | ||
