Full Automatic Chocolate Packing Machine

Full Automatic Chocolate Packing Machine thumbnail-1
Full Automatic Chocolate Packing Machine photo-1
US$ 4,200 - 6,600 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Commodity, Medical, Chemical, Other, Food, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type:
Bags, Film
Contact Supplier Request Quote Chat Now
Foshan SUK Precision Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Food, Commodity, Medical, Chemical, Other, Food, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type Bags, Film
Packaging Material Plastic
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage 220V
Power 2.6KVA
Place of Origin Guangdong, China
Brand Name SUK
Model Number 250
Weight 600KG, 600kg
Dimension(L*W*H) 3770x670x1450mm
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Superior quality;
2. Full automatic;
3. High speed;
4. Efficient Follow-up Service

Full Automatic chocolate packing machine:

Convey platform

transitional convey part

steering machine

automatic feeding part

packaging machine



Available feeding directions: the vertical and horizontal feeding system, vertical layout of workshop.



Packing material: Heat-sealable laminated film, such as: OPP,PE,PVC,PT/PE,OPP/CPP ,other special sealable packing film.



I. Main performance and structure features

1. Double frequency conversion control, bag length can be set and cut in one step, saving time and film;

2. Adopt PLC&HMI programming software, easy operating and setting;

3. Self failure diagnosis and clear failure display;

4. High sensitivity photoelectric eye color trace the bag, numerical input of cutting sealing position for extra accuracy;

5. PID control temperature independently which is more suitable for packing different materials

6. Positioned stop function, without sticking knife or wasting time;

7. Simple driving system, reliable working, convenient maintenance.

8. All control is realized through software and it can install intermittent air device and spray alcohol device. The adjustment can be realized at any time and technical upgrade.



II. Application



Cake, bread, biscuit, sweetheart pastry, green bean pastry, chocolate pastry, ect.



Automatic sorting system advantage:

Apply to both orderly and disorderly products.

Simple structure, convenient operation, and easy to set up.

Wide belt make the assembly convenient and fast.

Automatic feeding system advantage:

Accurate and quick positioning.

Convenient to set the machine when packing products of different specifications by simple adjustment.

The belt can be removable without tool.

Simple structure, easy cleaning.



III. Optional device

1. Coding machine
2. Air filling device

3. Punch machine

4. All stainless steel frame



IV. Specification of packing machine



Model
   SZ-250
Film width   Max.250mm
Bag  length   45~90mm
Bag  width   30~80mm
Product height  Max. 35mm
Film roll diameter   Max.320mm
Packing speed   60~330 bag/min
Power supply   220V,50/60HZ,2.6KVA
Size   (L)3770X(W)670X(H)1450mm
Weight   600Kg
Remarks  Optional air filling device



  V. Electric detailed list:



No.

Parts

Brand Name

1

7 inch touch screen

Wecon-Taiwan

2

Frequency Converter

Schneider-France

3

Controller/PLC

Panasonic or Schneider

4

Intermediate Relay

Schneider-France

5

Switching power supply

Meanwell-Taiwan

6

Temperature controller

YeaTai-Shanghai

7

Electric Eye

YeaTai-Shanghai

8

Solid state relay

Schneider-France

9

Encoder

PASO

10

Circuit breaker

MUNLAN

11

Terminal blocks

Weidmuller-Germany

12

Emergency stop switch

Schneider-France





Machine pictrues:



 Full automatic chocolate packing machine



Full automatic chocolate packing machineFull automatic chocolate packing machineFull automatic chocolate packing machine





Our Services



1. Video will be provided to customers.

2. Instruction book with every set of machine

3. Quick response to any question about the machine;

4. Competitive price as direct manufacturer

5. Superior quality

6. Best after-sale service





Packaging & Shipping

 Standard packing: Plywood case

Full automatic chocolate packing machine



Company Information

 Foshan SUK Precision Machinery CO.,LTD has been specialized in designing ,R&D and manufacturing kinds of packing machine for more than 6 years.  Ten series of products have been widely used in food, chemical, pharmaceutical, commodity, industrial and agricultural products, achieving automatic metering, feeding, bag making and conveying thus greatly improving the efficiency. We promise you superior quality and competitive price as direct manufacturer!

Full automatic chocolate packing machineFull automatic chocolate packing machineFull automatic chocolate packing machineFull automatic chocolate packing machineFull automatic chocolate packing machine
