YH04MJ-600
YH04MJ-600 -type stockings machine is controlled by the computer system with four weaving system and single cylinder jacquard stockings knitting machine,The machine uses an independent exhaust fan or central exhaust systems for stretch fabric, the Machines equipped with no torsion device,the cylinder direct drive servo motor rotation to reduce driveline and transmission error.By the three stepper motor control Shengke eyebrows and control cylinder to lift.it Can produce different density.Pressurized oil to lubricate Knitting and Sinker and needle selection tablets, the Computer control the whole process of making socks and Style and quality.In order to achieve the best results for jacquard,Yarn bobbin using lateral movement,The veil , bottom yarn , dyed yarn to achieve the best angle.The machine can use synthetic fiber , rayon and bare spandex yarn and Covering to produces stockings,The main productions are short socks , stockings , pantyhose and other types of socks.H04MJ-600 Stockings knitting machines can knit floating Elastic line to be full weave state.Not only can knit plain , mesh , jacquard , and each row can knit 2-3 color patterns organization , this feature is only H04MJ-600 -type to possess.
Function:
Type:YH04MJ-600
Needles diameter :4'' 4-1/2''
Needles&needle selectors: 192-400N,four Electronic needle selectors
Machine power cost :1.5KW
power supply :380V ;frequency: 50/60HZ
working Speed :450RPM(jacquard); Maximum: 700RPM
Average output:pantyhose 350/24hours ,short jacquard sock: 600 pair /24hours
Driving system :direct servomechanisms, synchronous belt drive
Weaving system :different choice of elastic ribbon or be tabby when all textile needle Working ,jacquard web like pattern,there are 2-3 designs in each row,be made in flower in flower.
Operation interface:display screen and keyboard inputting
Automatic stop: Infrared disconnected
oil system: automatic supply oil system.
Out size:2700mmX1300mmX1300MM(LxWxH)
Net weight:350kgs
Features:
1 Chinese and English display, large LCD display shows both character and figure.
2 Capacity of memory is 1M, can store many patterns.
3 Can input 2 patterns and 2 program files.
4 Computer control system can drive at most 6 ways of needle, 16 knives and 64 ways of air valve.
5 Pattern and program data can be input/ output by disk.
6 Equipped the UPS system can memory the current program and knitting action if transience power off. When the power restored, it can continue knitting to avoid any loss or wastage.
7 Password-protection for parameter setup, to avoid the inadvertent change or unallowed modification, improve the reliability and safety.
Characteristic:
Waist belt:The waist belt rise or fall control by pneumatic,have 2 work positions,knitted the waist belt at high position and knitted the fabric at low position.
Clippers device:The clippers rise and fall control by pneumatic.if yarm not cut off hall alarm automatically,also can blow the air to clean the slit up yarn and reduce the machine breakdown.
Stitch density:The stitch cam have enter and exit work position function.can knil multiple feeders pattern,also have work status test function and machinc in abnormally starus shall auto-stop and alarm.Adopt cam and air cylinder to achieve the stitch adjust without interval.Machine equip the high speed stcpping motor will achieve the 3D function.
Actuaror:Adopt 16 leves electric ceramic actrator.strueture easily reliable low energy consumed ahd low generate heat.
Cylinder up/down;the cylinder rise and fall eontrol by stepping molor,which can substantially adjust the stitch density.The cylinder height position shall decide the stitch density basis value.
Lubricate:Lubrication by mechanic control,which lubrication during macking revolution,because the pantyhose machinc is high speed runing and must continuous lubrication when machine revolution,which control the temperature rises and reduce the machine abradc.
Air compressor:To have functions of drainage.air pressure adjustment and alarm or lack air pressure.
Yam feede:4 feeder,each feeder with 6-8 yam fingers and each finger with 2 work positions.Change yam finger by pneumatic control,cach yam finger with high and low 2 work positions,the yam figer can move to left or right and knit the jacquard pattem.Whole yam finger device can bottom over,which easily for maintenance.
Drop hood:Control by 2 stepping motor though rough adjust the 2sets cam position with stitch press cam to achieve the fabric stitch density adjustmen,mainly uscd to achieve the take down width for knitted rib pattem.Another stetting molor can adjust the posifion of dropt hood.
Dial jacks:Control by electric magnetism vale.avoid pantyhose machine rewolution by high speed and knitted waist belt pattem.shall bring needle miss and make fabric defective.
Take down:The take down device control by suction and structure simply,enable the knitting fabric pulling foree even ahd without spoil the fiber of knitting fabric.The resist twist device prevent the twisting for wrinkle during knitted the fabric with hosicry tube bring the proportion rub and damage the fabric,which cnhancc the fabric surface quality.
Manual operation:Adopt fold type.which easy to maintain.the limit position protect control by pneumatic:I Ensure during the machine revolution will not use the manual operation;2 During use the manual opcration,machine will not use the motor driven.
YH04E7-600
fine stitch jacquard filar sock machines
H04E7-600 -type stockings machine is controlled by the computer system with four weaving system andsingle cylinder jacquard stockings knitting machine,The machine uses an independent exhaust fan or central exhaust systems for stretch fabric, the Machines equipped with no torsion device,the cylinder direct drive servo motor rotation to reduce driveline and transmission error.By the three stepper motor control Shengke eyebrows and control cylinder to lift.it Can produce different density.Pressurized oil to lubricate Knitting and Sinker and needle selection tablets, the Computer control the whole process of making socks and Style and quality.In order to achieve the best results for jacquard,Yarn bobbin using lateral movement,The veil , bottom yarn , dyed yarn to achieve the best angle.The machine can use synthetic fiber , rayon and bare spandex yarn and Covering to produces stockings,The main productions are short socks , stockings , pantyhose and other types of socks.
Function:
Type:YH04E7-600
Needles diameter :4'' 4-1/2''
Needles&needle selectors: 192-400N
Knitting system : 4 feed
Machine power cost :1.5W
power supply :380V ;frequency:50/60HZ
Rated Current:8.5A
Pattern input mode : USD Interface
Needle selector:each feed have a needle selector with 16 Piezoelectric off.
working Speed :450RPM(jacquard); Maximum: 700RPM
Density adjustment: divided into cylinder, density triangle , raw grams triangle, three parts , adjust the density of the fabric .
Automatic stop: Infrared disconnected
oil system: automatic supply oil system.
Out size:2700mmX1300mmX1300MM(LxWxH)
Net weight:350kgs
Characteristic:
Waist belt:The waist belt rise or fall control by pneumatic,have 2 work positions,knitted the waist belt at high position and knitted the fabric at low position.
Clippers device:The clippers rise and fall control by pneumatic.if yarm not cut off hall alarm automatically,also can blow the air to clean the slit up yarn and reduce the machine breakdown.
Stitch density:The stitch cam have enter and exit work position function.can knil multiple feeders pattern,also have work status test function and machinc in abnormally starus shall auto-stop and alarm.Adopt cam and air cylinder to achieve the stitch adjust without interval.Machine equip the high speed stcpping motor will achieve the 3D function.
Actuaror:Adopt 16 leves electric ceramic actrator.strueture easily reliable low energy consumed ahd low generate heat.
Cylinder up/down;the cylinder rise and fall eontrol by stepping molor,which can substantially adjust the stitch density.The cylinder height position shall decide the stitch density basis value.
Lubricate:Lubrication by mechanic control,which lubrication during macking revolution,because the pantyhose machinc is high speed runing and must continuous lubrication when machine revolution,which control the temperature rises and reduce the machine abradc.
Air compressor:To have functions of drainage.air pressure adjustment and alarm or lack air pressure.
Yam feede:4 feeder,each feeder with 6-8 yam fingers and each finger with 2 work positions.Change yam finger by pneumatic control,cach yam finger with high and low 2 work positions,the yam figer can move to left or right and knit the jacquard pattem.Whole yam finger device can bottom over,which easily for maintenance.
Drop hood:Control by 2 stepping motor though rough adjust the 2sets cam position with stitch press cam to achieve the fabric stitch density adjustmen,mainly uscd to achieve the take down width for knitted rib pattem.Another stetting molor can adjust the posifion of dropt hood.
Dial jacks:Control by electric magnetism vale.avoid pantyhose machine rewolution by high speed and knitted waist belt pattem.shall bring needle miss and make fabric defective.
Take down:The take down device control by suction and structure simply,enable the knitting fabric pulling foree even ahd without spoil the fiber of knitting fabric.The resist twist device prevent the twisting for wrinkle during knitted the fabric with hosicry tube bring the proportion rub and damage the fabric,which cnhancc the fabric surface quality.
Manual operation:Adopt fold type.which easy to maintain.the limit position protect control by pneumatic:I Ensure during the machine revolution will not use the manual operation;2 During use the manual opcration,machine will not use the motor driven.
YH10/12-400
automatic computer high-speed flat silk sock machines
main specification:
Needles diameter :4'' 4-1/2''
Needles&needle selectors: 192-480N,the second and forth braided lines use the eighth-grade pneumatic to select needle;the first and third braided lines use the 16th-grade pneumatic to select needle.
Machine power cost :1.5W
Electrical source :380V ;frequency 50/60HZ
Working Speed :450RPM(jacquard); Maximum: 700RPM
Driving system :direct servomechanisms, synchronous belt drive
Weaving system ;different choice of elastic ribbon or be tabby 1*1,3*1 fixed meshes when all textile needles working,T-shape crotch secured with 1*1,each elastic ribbon can made in full wave state.
Opweation interface:display screen and keyboard inputting
Automatic stop: broken infrared Fuel system: automatic fuel system
MATEC HS 4"x400n, 7mm latch
MATEC SC PLUS 4"x400n, 7mm latch
MATEC HF4.7s, 4"x400n, 7mm latch
Features:
1 Chinese and English display, large LCD display shows both character and figure.
2 Capacity of memory is 1M, can store many patterns.
3 Can input 2 patterns and 2 program files.
4 Computer control system can drive at most 6 ways of needle, 16 knives and 64 ways of air valve.
5 Pattern and program data can be input/ output by disk.
6 Equipped the UPS system can memory the current program and knitting action if transience power off. When the power restored, it can continue knitting to avoid any loss or wastage.
7 Password-protection for parameter setup, to avoid the inadvertent change or unallowed modification, improve the reliability and safety.
Characteristic:
Waist belt:The waist belt rise or fall control by pneumatic,have 2 work positions,knitted the waist belt at high position and knitted the fabric at low position.
Clippers device:The clippers rise and fall control by pneumatic.if yarm not cut off hall alarm automatically,also can blow the air to clean the slit up yarn and reduce the machine breakdown.
Stitch density:The stitch cam have enter and exit work position function.can knil multiple feeders pattern,also have work status test function and machinc in abnormally starus shall auto-stop and alarm.Adopt cam and air cylinder to achieve the stitch adjust without interval.Machine equip the high speed stcpping motor will achieve the 3D function.
Actuaror:Adopt 16 leves electric ceramic actrator.strueture easily reliable low energy consumed ahd low generate heat.
Cylinder up/down;the cylinder rise and fall eontrol by stepping molor,which can substantially adjust the stitch density.The cylinder height position shall decide the stitch density basis value.
Lubricate:Lubrication by mechanic control,which lubrication during macking revolution,because the pantyhose machinc is high speed runing and must continuous lubrication when machine revolution,which control the temperature rises and reduce the machine abradc.
Air compressor:To have functions of drainage.air pressure adjustment and alarm or lack air pressure.
Yam feede:4 feeder,each feeder with 6-8 yam fingers and each finger with 2 work positions.Change yam finger by pneumatic control,cach yam finger with high and low 2 work positions,the yam figer can move to left or right and knit the jacquard pattem.Whole yam finger device can bottom over,which easily for maintenance.
Drop hood:Control by 2 stepping motor though rough adjust the 2sets cam position with stitch press cam to achieve the fabric stitch density adjustmen,mainly uscd to achieve the take down width for knitted rib pattem.Another stetting molor can adjust the posifion of dropt hood.
Dial jacks:Control by electric magnetism vale.avoid pantyhose machine rewolution by high speed and knitted waist belt pattem.shall bring needle miss and make fabric defective.
Take down:The take down device control by suction and structure simply,enable the knitting fabric pulling foree even ahd without spoil the fiber of knitting fabric.The resist twist device prevent the twisting for wrinkle during knitted the fabric with hosicry tube bring the proportion rub and damage the fabric,which cnhancc the fabric surface quality.
Manual operation:Adopt fold type.which easy to maintain.the limit position protect control by pneumatic:I Ensure during the machine revolution will not use the manual operation;2 During use the manual opcration,machine will not use the motor driven.
Packing:
For a long journey, our company always use wooden packaging machines, and use screws machine 4 feet, making the machine minimize the degree. Our company adopts two points of the container, 20 feet and 40 feet. 20 feet can hold 12 machines, 40 feet can pack 34 machines.
