960P ONVIF H.264 P2P IR CUT CMOS 1.3mp Pan Tilt Wifi Ptz Camera System ip Cctv System
US$ 23 - 60
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
VSTARCAM
Model Number:
C37A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
960P ONVIF H.264 P2P IR CUT CMOS Pan Tilt Cctv Camera System Wifi hd ip Security CameraUS$ 23 - 60MOQ: 1 Piece -
960P ONVIF H.264 P2P IR CUT CMOS Pan Tilt Cctv Camera System P2p Wifi Household ip CameraUS$ 23 - 60MOQ: 1 Piece
-
960P ONVIF H.264 P2P IR CUT CMOS Pan Tilt Cctv Camera Home P2p Video Surveillance Wireless Motion Sensor Hidden CameraUS$ 23 - 60MOQ: 1 Piece
-
VStarcam 960P Resolution IR Cut Pan Tilt Two Way Audio Night Vision 1.3mp Camera ipUS$ 28 - 35MOQ: 1 Unit
-
960P ONVIF H.264 P2P IR CUT CMOS Pan Tilt Cctv Camera Home P2p Video Surveillance Dome Baby Monitor CameraUS$ 23 - 60MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
VSTARCAM
Model Number
C37A
Type
Digital Camera
Style
Box Camera
Sensor
CMOS
Technology
Infrared
Special Features
Other, ONVIF/WPS
960P ONVIF H.264 P2P IR CUT CMOS 1.3mp pan tilt wifi ptz camera system ip cctv system
Product Description
VStarcam new ptz wifi wireless ip camera support ONVIF ,64G TF card , motion detection ,wireless PnP two way audio vstarcam mobile ip camera with NVR and NVS-K200.
Features
1. 12 LED, IR distance 10M. Lens 3.6 mm
2. Support ONVIF 2.0, RTSP protocol
3. WPS encryption
4. 960P,720P,VGA,QVGA triple stream
5. Two-way audio, Remote Pan/Tilt rotate
6. Wi-Fi/802.11/b/g/n,support dynamic IP
7. Motion detection, email alert, FTP upload
8. Iphone, 3G phone, Smartphone supported
9. Multi-language, Firefox, Safari, Google browser
10. Pan:355 degree, Tilt: 120degree, auto cruise
11. Support 64 G TF Card.
Specifications
| System | OS | Embedded Linux OS |
| system security | Three level user authority management | |
| online users | support 4 online visitors simultaneously | |
| DDNS | Free DDNS | |
| Control protocol | ONVIF 2.4 protocol, high interoperability | |
| Processor | Hisilicon processor,built-in ARM926 @Max. 440MHz and a high-speed video co-processor. | |
| Reset | Long press for 15 seconds to restore back to factory settings | |
| Collection | Image sensor | 1/3inch 960p Progressive scan CMOS sensor |
| CMOS | support AWB, AGC, BLC | |
| SNR | ≥39dB | |
| Minimum illumination | 0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode) | |
| Lens/viewing angle | 3.6mm@F1.4/56.14degree | |
| Night vision | Dual IR-CUT filter auto switch, 12pcs 850nmΦ5mm LED,10m IR distance | |
| IR control | IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode. | |
| Video | Compression Format | H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline |
| Video coding process | Multi-stream:960P/360P/180P+720P @1fsJPEG snapshot | |
| Resolution | 960P/360P/180P | |
| Bit Rate | CBR/VBR, output bit rate range:128~4096kbps | |
| Frame rate | 15fps | |
| Picture Adjustment | Contrast, brightness, saturation, chroma are adjustable. | |
| Audio | Input | Built in -48dB Microphone |
| Output | Built in speaker(8Ω1W) | |
| Sampling frequency / width | 8KHz/16bit | |
| Compression format | ADPCM/32kbps | |
| Network | Interface | 10Base-T / 100Base-TX, RJ45 connector |
| Network Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,ONVIFetc. | |
| WIFI | WiFi802.11b/g/n | |
| Antenna | 3dBi antenna,stronger signal, more stable | |
| Wireless network security | one key setup WiFi, do not need network cable . | |
| storage | Storage mode | Local storage / client storage/NVS /NVR storage |
| card | support 64G TF card . | |
| Interface | Micro SD | |
| Pan-Tilt | P/T | Pan:355degree,Tilt:120degree |
| Preset Postion | support up to 15 preset postions | |
| Limit method | Software limit position, more accurate preset positions,lower Pan Tilt failure rate | |
| Alarm | Motion detection | Support motion detection |
| Alarm action | Image upload via email/FTP server | |
| Physical index | Rated Voltage | DC5/2A±0.3V |
| Power comsumption | Rated power:3.0W(IR ON) | |
| Working environment | Working Temperature:-20~70degree,Working Humidity 90% | |
| Weight | Gross Weight :755g (Note: in kind prevail) | |
| Housing material | ABS plastics | |
| Camera size | 195x140x130mm (L×W×H) | |
| Installation | Wall mounting, ceiling mounting | |
| Packing | Canton size | 710*410*350mm 20pcs/carton |
| CTN: | 0.1 cubic meter/carton | |
| Gross Weight: | 15kg/carton | |
| Only for reference |
