Product Name: 8 Heads Cooking Oil Filling Machine
Model: ZLDG-8
Introduction
Scope of application
8 Heads Cooking Oil Filling Machine is widely used in filling a variety of oils and viscous liquids, such as peanut oil, blend oil, rapeseed oil and other edible oil filling.
Technical parameters of 8 Heads Cooking Oil Filling Machine
Filling speed: 1500-2000 (barrels / hour)
Filling capacity:20-30L
Filling accuracy: ± ≤ 0.1% FS
Power Supply: 220/380V 3 phase +Earth Wire, 50 Hz
Pressure: 0.5-0.8Mpa
Humidity: <98 %
Ambient temperature: 0~40°C
Principle Features of 8 Heads Cooking Oil Filling Machine
8 Heads Cooking Oil Filling Machine is pleasing in appearance,filling high-precision adjustment convenient, easy to
operate and so on.
1.8 Heads Cooking Oil Filling Machine has man-machine interface,direct set filler
2.8 Heads Cooking Oil Filling Machine is PL controlled,and frequency control linear filling
3.Hing-precision volumetric flowmeter,quantitative accurate and reliable
4.Mechanical seal and vacuum suction to double-drip.
5.After the slow first pair of fast filling velocity efficient.
6. 8 Heads Cooking Oil Filling Machine is widely used in various oil and filling viscous liquid, such as peanut oil, blend oil,canola oil filling.
7. 8 Heads Cooking Oil Filling Machine,filling in the application of various oil,such as lubricating oil,edible oil filling.
8.8 Heads Cooking Oil Filling Machine is equipped with touch-screen display,eight meters VVVF conveyors,automatic sensor-gland machines,vacuum with anti-drip.
Device Configuration of 8 Heads Cooking Oil Filling Machine
The main engine is made of stainless steel.
The parts contact with material is made of 304 stainless steel.
Janpan Keyen Ce sensor
France Schnaid relay element
Taiwan Airtac pneumatic element
Mitsubishi PLC and frequency converter
Product line include:main filing engine+4 m chain plate conveyor(stainless steek) + automatic induction sealer(which is suitable for pressing cover, not suitable for whorl cover)
Standard Export Packing for 8 Heads Cooking Oil Filling Machine
A.Cover by PVC film + fumigated wooden case;
B.Wooden case suitable for long distance ocean shipping.
Welcome to JINAN DONGTAI
Jinan Dongtai Machinery Manufacturing Co., Ltd.
our factory is a professional packaging machinery manufacturer over seventeen years and one of Chinease Gold Suppliers in china.Brief Introduction
Our business involves various markets all over the world and in many fields is with our excellent product. Now we have been one of the biggest manufacturer of packing machine in northeast of China, and exported our products to 21 countries, such as USA, Holand, AE, Canada, Brazil, Russia, Austrilia, India and so on.On the basis of excellent quality and competitive price, you will be surely get a big success in your industry.
Our Jinan Dongtai Workshop
For many years, we have devoted great efforts on researching and developing products under DONGTAI & XUNJIE brand, making remarkable quality, especially in filling machine and packaging machine.
Other Products
Our equipment is all adopted the advanced technology and Impoted famous brand raw materials at home and aborad.
At present, widely application various fields, such as various sachet packaging machines, packaging machine for liquid, sauce packing machines, beverage packing machines, vertical type packaging machines, granule packing machines, powder packing and filling machines, vacuum packaging machine, filling capping machines, bottle filling machines, semi-auto filling machine, automatic liquid filling machine, antifreeze filler, magnetic pump manual liquid filling machine, paste lotion filler, coding machine, sealing machine, electromagnetic induction sealing machine, labeling machine, shrinking machine, filling line, etc.
Filling production line included: Filling Machine + Capping Machine + Labeling Machine + Coding Machine + Shrinking Machine + .......
We as a manufacturer are specialized in all kinds of packaging machinery equipment.
Good experience of many years and to be devoted to the packaging industry for food, medicine, daily chemical, washing, beverage and other industries packaging, etc. No damage to human factors, all products one year warranty, life-long maintenance. If you have any problems, don't hesitate to contact us, please.
We can in a timely manner to provide customers with comprehensive after-sale service.
Dongtai has a highly sophisticated technical talent, has a high- quality team
Sincere service for your dedicated
