Specifications
1.CB-200A hydraulic copper tube bender2.output: 20T
3.max thickness:12mm
4.weight:18kg
5.good quality with low price
CB-200A hydraulic copper tube bender
Features:
1. this machine is a kind of flat bend copper, aluminum bus dedicated equipment.
2. CB-200A uses balt type structure, easy access to rows of copper and aluminum.
3. Equipped with supporting frames to ensure that copper and aluminum row center line and the
centerline of the piston in the same plane.
| Modle | Output(T) | Width(mm) | Max thickness(mm) | Size(mm) | Weight(kg) |
| CB-150A | 16 | 150 | 10 | 310X260X160 | 15.5 |
| CB-150D | 16 | 150 | 10 | 380X270X150 | 17.5 |
| CB-200A | 20 | 200 | 12 | 360X260X160 | 24 |
| MB-125 | 20 | 125 | 12.5 | 330X220X140 | 14 |
1. It is designed for bending Cu/Al bus bar.
2. With different bending angles.
3. With width position unit, bus bar won't distort after bending.
4. The unit body could be open so that bended object could be easily taken out after bending.
5. Portable unit could be taken to site or fixed in factory for batch bending word.
6. Max. bending angle 90 degree.
7. Bended object surface won't be damaged.
Primary Competitive Advantages:
1), Our company has several years’s experience in producing kinds of hydraulic bending tool, we have the self-operated importing and exporting rights.
2), All products are approved by ISO9001:2008 and CE.
3),We can produce the hydraulic tools according to our customer’s requirement.
4), We insist to popularize our brand “Zhenda” to our customers , and welcome to become our sales agency ,
We’ll give our customer the special prices once the customer become our approved agency
