700 bar hydraulic hand pump CP-700-2A

Specifications

1.700 bar hydraulic hand pump CP-700-2A
2.Low pressure:20kg/cm2
3.High pressure:700kg/cm2
4.Capacity of Oil: 1900cc

700 bar hydraulic hand pump CP-700-2A



Features:



 1 Hydraulic pumps to drive crimping head, cutting heads and punch head



2 Two stages speed action for rapid ram advantage



3 Manual operation style, oil pipe fitted with quick coupling could be ordered in any length. It could be fitted with pressure meter(to be ordered)



4 Accessories including 2M high pressure hose and coupler plug P/T 3/8” thread, oil must be changed half a year



Model No.	CP-700-2A
Max pressure rating	700kgf/cm²/psi
Pressure rating	low:  0-20 high: 20-700 kgf/cm²
Oil capacity	1900cc
Size	630x240x140 mm
Weight	12.22kg
Type	hand -operated



Primary Competitive Advantages:



1), Our company has several years’s experience in producing  kinds of hydraulic pumps, we have the self-operated importing and exporting rights



2), All products are approved by ISO9001 and CE.



3),We can produce the  hydraulic tools according to our customer’s requirement



4), We insist to popularize our brand “Zhenda” to our customers , and welcome to become our sales agency ,

We’ll give our customer the special prices once the customer become our approved agency
