Help CenterWaterproof 12V 2.5A 30W Constant Voltage Led Driver IP67
Related Products
-
300MA Constant Current LED Driver IP67 24V Dimmable LED DriverUS$ 1.05 - 2.8MOQ: 100 Pieces -
60W AC to DC Constant Current LED Driver(UL CUL CE)US$ 3.5 - 7.9MOQ: 100 Pieces
-
12V 20W Led Driver AC DC Switching Power SupplyUS$ 1.27 - 2.9MOQ: 100 Pieces
-
Output 12v 0.1-0.833a Constant Voltage 10w Led Driver Size 90*30*20mmUS$ 1.37 - 2.72MOQ: 100 Pieces
-
700mA DC 9-15V Dimming Led Driver Size 80*42*24MMUS$ 2.2 - 4.67MOQ: 100 Pieces
30W Constant Voltage LED Driver
Voltage Range: 90~264VAc
Frequency Range: 47~63Hz
Efficency: >85%
AC current (max): 0.7A @ 220V, 2.0A @ 115V
AC Inrush Current: 40A @ 230V
DC Voltage: 24V
Rated Current: 300mA
Ripple & Noise (max): mVp-p < 1% Uout
Load Regulation: +/- 1%
Setup Time: 500ms
Rise Time: 20ms
Hold UP Time: 30ms @ 230V, 10ms @ 115V
Short Circuit Protection
Overload Protection: 130~150%
Over Voltage Protection: 115~135%
Thermal shutdown
Working Temperature: -20~50℃
Working Humidity: 20%~90% RH
Storage Temperature: -40~60 ℃
Storage Humidity: 20%~95% RH
Safety Standard: meet CE, FCC, GB,CCC, ROHS
Withstand Voltage: IP/OP 5mA 2KVAc
Isolation Resistance: IP/OP 100M Ohms
Waterproof Rank: > IP67
Dimension: 200*30*20mm
Our factory:
5,000 square meters
150 well-trained staffs
18 R&D engineers
18 QC auditors
4 SMD workshops, equipments imported from Japan
2 semi-automated production lines
500K/M current monthly capacity
ISO9002 quality assurance
UL/CUL , CE, FCC, CCC, KC, GS, TUV , C-TICK , SAA,CB, ROHS approvals , 6 level efficiency .
Our principle: Lowest price and GOOD quality.
