Specifications
tungsten crucible1. Specification: OD: 50-150mm;
Height: 50-200mm
2.Meterial:W1, W2, WAL1, WAL2,
pure tungsten crucible
1.Grade: W1, W2, WAL1, WAL2, WAL3
2. Purity: W≥99.95%
3.Characteristic:
Melting Point: 3410 DC
Boiling Point:5927 DC
Density: 18.5 - 19.3 g/cm3
Size:OD:50-150mm;
Height:50-200mm ;
4.Certificate: ISO9001:2008
5. Product Feature: high-purity, high-density, no internal-crack.
6. Dimensions and tolerance(According to clients’ requirements
Delivery |
Specification |
Tolerance |
Thickness |
Roughness |
|||
Diameter |
Height |
Diameter |
Height |
||||
Sintering |
10~500 |
10~750 |
+/-5.0 |
+/-5.0 |
8~20 |
<3.5 |
|
Sintering |
10~450 |
10~550 |
+/-0.5 |
+/-0.5 |
7~18 |
<2.5 |
|
7. Application:
Since the melting point of tungsten has reached 3410°C, tungsten crucible is widely applied in industry furnace such as sapphire growth furnace, quartz glass melting furnace, and reare earth smelting furnace. The temperature in working environment of tungsten crucible is above 2000°C. For sapphire crystal growth furnace, high-purity, high-density, no internal-crack tungsten crucible with other features of exact measurement and smooth inner surface has decisive influence on success ratio of seed growth, quality control of pulling crystal, metamictization pot-committed and service life during sapphire growth process.
Thanks for your visit to our website, welcome to receive your enquiry and looking forward to work with you in the near future!
