price of 6mm air conditioner copper tube as air conditioner connector
- 6000 Set / Sets per Month
- ShenZhen GuangZhou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
casing pipe from dongguan, precision air conditioning unit
-
copper tube condenser coil for ac 1.05 ton window air conditioner, home air conditioner parts
-
copper pipe roll assembly for air conditioners
-
3/8 c1220 copper pipe/tube for 1 ton wall split air conditioner
-
6.35 mm pre insulated copper pipe for 0.5 ton room air conditioner
-
100% 3/4 inch solar air conditioner copper pipe from guangzhou
Product Details
Type | Other, Air Conditioner Parts, Air Conditioning Fitting | Application | Home | |
Certification | Other, RoHS | Place of Origin | Guangdong, China | |
Brand Name | YD | Model Number | YD-C145830WB |
Product Description
price of 6mm air conditioner copper tube as air conditioner connector
- The length and wall thickness of pipe, copper nut and insulation can be customized.
- Advance cutting machine promote precision.
- Powerful hydraulic expanding machine makes surface of inner or outer wall smooth.
- Short delivery time, 3-7 working days.
- Small order is also welcomed.
Mechanical Properties of air conditioner copper pipe
- Pure copper matrial with good stretching resistance, content of C1220 copper reaches 99.9%.
- Inside Interor surface maximum permissible residue 0.038g/m ² .
- Tensile strength(Mpa)>205, elongation(%)>40.
- No defects on the surface of air conditioner copper pipe during production, avoiding hidden trouble.
- Dimension and mechanical properties complied with ASTM B280, EN12735-1, AS1571, JIS H3300.
- High temperature resist(120℃), flame resist standards: USA UL-HF-1, France M1, Australia BL-s1-d0, China B1
- Anti-aging and ultraviolet. After 200-hours-irradiation of Xenon arc Lamp, there is no wrinkle, pinhole, pulverization or cracking situation occurs for our products. Therefore the anti-aging ability of insulation tube could be assumed approximately 8-10 years.
- Ability of preventing condensation of water vapor, working temperature is from -70 ℃ to 120 ℃ as environment condition. Moisture permeability coefficient is ≤1.3x10-10.
- Europe Rohs standard, Lead, Cadmium, Mercury, Hexavalent Chromium, Polybrominated Biphenyls and Polybrominated Diphenyl Ether tests are all qualified.
Spec.(inch) | Metal tube outer dia.*wall thickness(mm) | Insilating thickness (mm) | Length(m) | Quantity per carton |
---|---|---|---|---|
1/4"+5/8" | 6*0.8+15.88*1 | 8 | 30-50 available | 5 |
Other models
Spec.(inch) | Metal tube outer dia.*wall thickness(mm) | Insilating thickness (mm) | Length(m) | Quantity per carton |
---|---|---|---|---|
1/4"+1/2" | 6*0.8+12.7*0.8 | 8 | 30-50 available | 5 |
1/4"+3/8" | 6*0.8+9.52*0.8 | 8 | 30-50 available | 5 |
3/8"+5/8" | 9.52*0.8+15.88*1 | 8 | 30-50 available | 5 |
3/8"+3/4" | 9.52*0.8+19.05*1.2 | 8 | 30-50 available | 5 |
1/2"+3/4" | 12*0.8+19.05*1.2 | 8 | 30-50 available | 5 |
Items | Test method | Result |
Airtightness property | 4.0MPA, 5 min | No leak |
Presure resistance | 12MPA, 1 min | No crackle |
Bendability | Diameter 180 deg | No pleat and crackle |
Nylon bage or hard paper carton. Or as customer's request.
1 The length of pipe, brass rods and wall thickness of air conditioner copper pipe can be customized.
2 Quick response. Quotation for air conditioner copper pipe will be provided within 48 hrs.
3 Free sample of air conditioner copper pipe can be available.
4 Professional engineer with six year experience to solve your problem regarding air conditioner copper pipe.
5 Excellent afer sale severce, 100% compensation if any quality problem.
Dongguang YiDu Refrigeration Technology Co.,Ltd was established in 2009, specializing in the RD and manufacture of refrigeration accessories,especially the cooper/aluminum connecting pipe for air conditioner. Product arrange includes the central air-conditioner heat preservation copper tube, air-conditioning aluminum tube, air-conditioner coating tube. Due to innovative improve technology, YiDu can ensures 4 mian advantages compared with other competitors. A First class cutting machine would not hurt pipes, avoiding narrowing size, leakage or water drop. B Excellent welder with gas bar, makes sure the inside of pipe completely empty, no occlusion, meanwhile keep original size. C 100% no aluminum slag. D OEM service, the length and wall thickness of airconditioning pipe or insulation pipe can be customized. For six years,YiDu has already built a well-earned reputation for producing the finest products with reasonable cost. Manufacture capacity can reach 4k-6k sets daily. Products have been exported to Europe, America, Japan, Middle East, Southeast Asia,and so on. Welcome to contact our sales for quotation.
