Level Switch
1. Our raw materials passed UL , SGS, FDA , quality is reliable and stable.
2. All kinds of float ball materials and sizes for your choice.
3. We can customize specification as your requirements. Welcome OEM or ODM.
4. Small MOQ: 500pcs
A float switch is a device used to sense the level of the liquid in a tank. The float ball of the level sensor will rise or fall with the liquid and when it moves to a certain area, the magnetic force of the magnet inside the float ball will cause the reed switch to turn on, and when it moves away from this certain area, the reed switch will turn off.
If there is no product that fit your desire, you may tell us the detailed information or your demand of the product, we will design and manufacture the products for you particularly!
| FS-25 | FS-52 | FS-50 |
|
|
|
|
|
|
| Max Contact Rating | 10W |
| Max Switching Voltage | 100VDC |
| Max Switching Current | 0.5A |
Min Breakdown Voltage |
250VDC |
| Max Carry Current | 1.0A |
| Max Contact Risistance | 100mΩ |
| Temperature Rating | -10~85°c |
| Float Ball Material | PP |
| Float Body Material | PP |
| Hexagon Nut Material | SUS304 |
The data will change for every reed switches
We have two types for A and B, please note as below picture
|
|
|
|
|
|
Sincerely hope to be the best partner with you!
