PP Material Water Detection Magnetic Float Switch
US$ 1 - 3
/ Piece
100 Pieces(Min. Order)
- HONGKONG
You May Like
-
Customized PP Material Water Detection Magnetic Level Switch
-
Customized PP Material Water Detection Level Switch
-
Magnectic Water Level Switch
-
Vertical Magnetic Water Float Sensor-Polypropylene Material-2015
-
Horizontal PP Level Sensor
-
Stainless Material Level Switch in Vertical Installation for Liquid Level Control
Product Details
| Place of Origin | Guangdong, China | Brand Name | ERLANG | |
| Model Number | FS-35-M10 | Usage | Magnetic Sensor | |
| Theory | Other, REED SWITCH | Output | Switching Transducer |
Product Description
Product Description
Magnetic Float Switch
Movement Explaination:
A float switch is a device used to sense the level of liquid in a tank.
When the float ball moves along the stem with the water level, the magnet inside the ball will cause the action of the reed switch inside the stem. And the action of the reed switch will energized or cut off the circuit, this will send to the control board a signal that the liquid level is at the predetermined position, then we will know the condition in the tank.
there are usually two way to use the float switch, to prevent overflow or to prevent dry-fire.
Application:
water heater, water dispenser, air-condition, air-cooler, BSD-P, humidifier, dehumidifier,fluid control,a pump,an
indicator,an alarm,or other device.
If there is no product suitable for your desire,you can also send some data and pattern of your
product that you desired ,our company will design it for you particularly!
Our products has been authenticated by ISO9001.
| Data Scan | FS |
| Max Contact Rating | 10W |
| Max Switching Voltage | 100VDC |
| Max Switching Current | 0.5A |
| Min Breakdown Voltage | 250VDC |
| Max Carry Current | 1.0A |
| Max Contact Resistance | 100mΩ |
| Temperature Rating | -20~85°C |
| Float Ball Material | PP |
| Float Body Material | PP |
| Hexagon Nut Material | PP |
FORM A: when the float ball go down the switch is TURN ON
FORM B: when the float ball go down the switch is TURN OFF
