Glass Bottle and Washing Machine

FOB Price

US$ 9,000 - 12,000 / Unit

1 Unit(Min. Order)

Port Shanghai
Payment TermsT/T Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	MODERN PACK
Model Number	XP		Processing Types	Glass bottle

Product Description

XP-I type of bottle washer mainly consists of inner brusher (main body), out- brusher (auxiliary device) and steeper. Main body of this machine drives two sets of dialing wheel, which moves intermittently, to feed bottles and wash inner surface of bottles. At the same time, auxiliary device washes outside surface of bottles with its five brushes, which arranges in positive and negative directions...

Specs of bottles	O.D. of bottle (mm)	58±1		64±1			75±1
	Bottle height (mm)	200±1.0		197±1.5			290±1.0
Washing efficiency	XP-I		XP-Ⅱ			XP-Ⅲ
	4000~4300 b/h		3000~3200 b/h			2800~3000 b/h
Main body of machine	Main motor				1.1kw
	Motor of inner brusher				0.55kw
	Speed of inner brusher				505 rpm
	Pressure of water supply				0.3MPa
	Speed of bottle feeding				7.24 m/min.
	Rotary speed of dialing wheel				7.28 s/r
	Overall dimension (L×W×H mm)				1700×1320×1300
	Weight (kg)				1000 kg
Outside brusher for removing label on bottles	Motor of conveyor				0.75kw
	Speed of conveyor				11.13 m/min.
	Motor of out- brusher				0.75kw
	Speed of out- brusher				700 r/min.
	Motor of pump				0.37kw
	Water consumption				2.8 m³/h
	Overall dimension (L×W×H mm)				2900×1920×1850
	Weight (kg)				600kg
Steeper	Temperature of solution				45~55°C
	Concentration of solution				NaOH 1.4%
	Overall dimension (L×W×H mm)				2100×1920×1850
	Weight				450kg
