Door Frame Roll Forming Machine/Steel Metal Door And Window Frame Making Machine/Gate Frame Production Machine Line/garage Door

Specifications

TECHNICAL PLAN

Material Spec                          carbon steel or galvanized sheet;

Coil stress                               235Mpa

Main motor power                  7.5kw

Working Speed                      10 ~ 12 m/min.

Cutting Tolerance                 ≤±2.5mm ( length≤ 5000mm)

                                                  ≤±3mm ( 5000mm < length ≤ 10000mm)

Type of cutting                       Roll-formed and length-set cutting

Voltage                                  380V 3 phase 60Hz or at buyer`s requirement

Material of Main Equipment

Roller Material                    GCr 15, with digital-controlled procession, quenching

Active Shaft Material          High grade No.45 carbon wrought steel,which can improve the integrated mechanic feature of the shaft Φ75mm.

Electric Elements              PLC control panel, transducer imported from Mitsubishi of Japan.

Other elements from famous suppliers in China

Cutter blade                     Cr12 mould steel with quenched treatment for U guide,and three piece cutter blade,,means that there are about 15mm material waste if cutting.

Standard Equipment of Machine

decoiler with 1T                         1set

Guiding Equipment                  1set

Roll Forming Equipment         1set

Post Cut Equipment                1set

Hydraulic Station                     1pc

PLC Control Panel                 1pc

Supporter Table                      2pcs

Different profiles view
