Specifications
filling machine
1)carbonated drink
2)4000BPH
3)Stainess steel
4)Certification:CE/ISO90001/BV/TUV/GMC
filling machine
Main Parameter:
Model | DGCF16-12-6 | DGCF18-18-6 | DGCF24-24-8 | DGCF32-32-10 |
Production Capacity(B/H) | 2000-4000 | 4000-6000 | 6000-8000 | 8000-12000 |
Filling Precision | <=5mm(Liquid Level) | |||
Filling Pressure(MPa) | <0.4 | |||
Polyester Bottle Satandard(mm) | φ40-φ80 | Bottle Diameter: φ50-φ100 Height:150-320 | ||
Suitable Cap Shape | Plastic Screw Cap | |||
Water Pressure of Washing Bottle(MPa) | 0.18-0.25 | |||
Water Consumption for Washing Bottle(kg/h) | 1300 | 2000 | 2500 | 3000 |
Spraying Position | 5 | 5 | 6 | 12 |
Dripping Bottle Position | 2.5 | 3.0 | 3.5 | 7 |
Gas Source Pressure(MPa) | 0.4 | |||
Gas Consumption(m³/min) | 0.3 | 0.4 | 0.4 | 0.5 |
Total Power(kw) | 5.03 | 5.03 | 6.57 | 8.07 |
Total Weight(kg) | 2000 | 3000 | 4000 | 5000 |
Dimension(L*W*H)(mm) | 2100*1500*2200 | 2450*1800*2200 | 2750*2180*2200 | 3600*2200*2600 |
Zhangjiagang Modern Beverge Packing Machinery Co.,LTD. is a collection development, research, design, production and technical services and marketing into one professional engaged in the manufacture of mechanical equipment packages beverages, food packaging machinery equipment, high-tech enterprises. Companies have excellent development and design system experienced technical team, continually introducing Italy, and Germany abroad latest beverage packaging machine games, focusing on the reliability of the overall performance, development and improvement of their own products. Our company mangaerial concept is "cooperate honestly,base on the credit,be superior in quality".We would like to cooperate with all old and new customers to co-develop,establish long-term stable business relationship,and make a bright future together. Provide long-term mineral water, pure water (bpd) gasoline production lines on a tea, juice beverages hot, cold beverage production lines on a carbonic acid beverages bottled production line on a beverage tastes gasoline production lines on a purely Shengpijiu gasoline production lines on a yellow wine and white spirit, wine beverage production lines and various ancillary equipment, and the turnkey contract works.
