Home > Manufacturing & Processing Machinery > Building Material Making Machinery > Tile Making Machine > WLFM20-185-925 Metal Roof Sheet Machine for Glazed Tile Forming Machinery

WLFM20-185-925 Metal Roof Sheet Machine for Glazed Tile Forming Machinery

Name: WLFM20-185-925 Metal Roof Sheet Machine for Glazed Tile Forming Machinery
Brand: WILLING
SKU: 127402647
Availability: InStock

Hangzhou Willing International Co., Ltd.

WLFM20-185-925 Metal Roof Sheet Machine for Glazed Tile Forming Machinery thumbnail-1

WLFM20-185-925 Metal Roof Sheet Machine for Glazed Tile Forming Machinery photo-1

US$ 34,000 - 44,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Tile Forming Machine

Tile Type:

Glazed

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Ningbo China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Tile Forming Machine

Tile Type Glazed

Use Roof

Production Capacity 0-3m/min

Place of Origin Zhejiang, China

Brand Name WILLING

Model Number WLFM20-185-925

Power(W) 11kw

Voltage 380V or as buyer's request

Dimension(L*W*H) 7800mm*1500mm*1500mm

Weight 7000kg

Certification CE, ISO9001:2008, Soncap, AAA credit

Warranty 12 month

Specifications

Coil width: 1000mm
Effective width: 925mm
Roller driven type: chain transmission
Controller: PLC

WLFM20-185-925 metal roof sheet machine for glazed tile forming machinery

1. Profile drawing

2. Machine layout

3. Main parameter

Material spec:	Color steel sheet;
Thickness:	0.3 mm to 0.7 mm
Coil width:	1000mm
Working speed:	0-3m/min. (Nodal distance at 250mm)
Cutting tolerance:	±2mm
Main motor power:	5.5Kw
Hydraulic station power:	5.5Kw
Decoiler	manual decoiler, max capacity 5000kgs
Main roller qty:	about 14 stands but depends on last design
Type of cutting:	Roll-formed and length-set cutting
Main body dimension:	About 7800mm1500mm1500mm

4. Machine picture

5. Working flow

Decoiling the sheet------Sheet guiding------Roll forming------Pressing the panel------Measure length------Cutting the panel------Panels to the supporter

6. Standard quipment

5tons passive uncoiler	1set
Pre-cutting equipment(Optional)	1set
Film covering device (Optional)	1set
Guiding Equipment	1set
Roll Forming Equipment	1set
Pressing equipment	1set
Post Cut Equipment	1set
Hydraulic Station	1set
PLC Control Penal	1set
Supporter Table	2sets
