Product Feature:
1Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted
3Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment throughly.
5splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel ,within ten minutes.
bottle filling machine
Water Filling Machine/ Filling Machine
1. monoblock, 3 in1
2. capacity: 2000bph to 24000bph
3. Fully automatic, for 0.5 to 2L
Water Filling Machine/ Filling Machine
The water filling machine is mainly used in the beverage filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic. The machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles. The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications. The advanced OMRON programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably
| Model: | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 | CGF40-40-10 | ||
| capacity :500ml | 5000 | 8000 | 12000 | 16000 | ||
| bottle shape: | roud or square | |||||
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
| cap: | PE srew cap | |||||
| filling precision: | ≤±5mm | |||||
| filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
| rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
| filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
| overall size:(mm) | 2450*1800 *2350 |
2780*2200 *2350 |
3600*2650 *2350 |
3800*2950 *2400 |
||
| weight: (kg) | 3500 | 4500 | 5500 | 6500 | ||
When you send inquiry,please also included the capacity and bottles shape and bottle volume you need to work on the machine, it is easy and accurately for us to recommand a right machine!
If any special,our manufacture also can design the machines according your requirement.
