General Specification
Tunnel Size-------------------------800(W)*650(H) mm
Conveyor Speed------------------- 0.22m/s
Conveyor Max Load---------------170kg
Dose per Inspection----------------< 1.6μGy/h
Resolution---------------------------< 0.0787mm Copper Wire
Spatial resolution-------------------Level: dia1.3mm, Vertical: dia1.0mm
Penetrate resolution--------------Dia 0.511mm
Penetration-------------------------- 34mm Steel
Film Safety---------------------------Guarantee ISO1600 Film
X-ray Leakage-----------------------<0.1μGy/h (at a distance of 5cm From external housing)
X-ray Generator
Generate direct-------------------------Downward
Generate angle-------------------------80 degree
Anode Voltage--------------------------100~160Kv
Anode power----------------------------0.4 to 1.2mA
Cooling / Duty Cycle------------------Oil Cooling /100%
Operation temperature/Humidity----- 0°C-45°C/20%-95%(non-condensing)
Storage Temperature/Humidity-------- -20°C-60°C/20%-95%(non-condensing)
Operation Power---------------------------220VAC(±10%)50±3Hz
Power Consumption-----------------------1.0 KW (max)
Noise: --------------------------------------<58db
our sales will reply you within 12 hours after receive your iquiry
we insisit professional dedicated spirit of service ,adhere to the market demand ,customers requierments as our responsibility.Rlying on advanced technology,excellent team and modern management for customers to provide the lastest market imformation and best servive ,to achive a win-win aim.
