Specifications
Realible and Professional Screw Air Compressor Manufactrurers1.Type:JMS-30A
2.Reliable and professional working Team
Realible and Professional Screw Air Compressor Manufactrurers
Part 1.Features of this Units
1.Adopting the efficient belt pulley rotation mode, driving the main engine to compress air, refrigerating the compressed air through the oil injection. The air and oil-mixed gases discharged from the main engine separated through rough and refined processes, and the separates the oil from the compressed air, and finally get the pure compressed air.
2.We products have the features of reliable performance, and simple operation process, small vibration, lower noises, less consumable parts, high working effiency, great power balance, and suitable for low voltage big flow occasion.
Part 2.Main Parameter
Specifications |
Type |
Power (KW) |
Rotating Mode |
Air discharging(M3/MIN) |
Size(MM) |
Weight(KG) |
Working Pressure |
10HP |
JMS-10A |
7.5 |
Belt |
1.1 |
890*630*920 |
240 |
0.8MPA |
15HP |
JMS-15A |
11 |
Belt |
1.53 |
1066*856*1125 |
450 |
0.8MPA |
20HP |
JMS-20A |
15 |
Belt |
2.4 |
1066*856*1125 |
470 |
0.8MPA |
30HP |
JMS-30A |
22 |
Direct Belt connection |
3.56 |
1050*900*1150 |
650 |
0.8MPA |
50HP |
JMS-50A |
37 |
Direct Belt connection |
6.26 |
1180*100*1310 |
1060 |
0.8MPA |
75HP |
JMS-75A |
55 |
Direct connection |
10.1 |
1666*1336*1695 |
1900 |
0.8MPA |
100HP |
JMS-100A |
75 |
Direct connection |
12.7 |
20445*1250*1705 |
1820 |
0.8MPA |
Part 3.Applications and Adantages
◊ Easy for installation;
◊ Low power consumption;
◊ Water cooled;
◊ Simple product struction and maintenance,realiable,suitable for the gas which are high purity,rare and precious,flammmable&combustible,posionous &harmful,and high voltage.
◊ Mainly used for Aviation,Medicines,petrochemical,scientifical Experiments and so on and so forth.
Part 4. About Our Company
We specialize in producing air separation plants, CO2 recovery plants with or without source gas, cryogenic liquid storage tanks (LO2, LN2, LAr, LCO2, LNG and LPG), ISO tanks, semi-trailer tankers, vaporizers, gas filling stations, cylinders and dewars, dry ice machines, compressors and cryogenic pumps etc. Pls feel free to contact us for further information, we are here ready for you!
Part 5. Certificates:
Part 6.Relevant FAQ required
1.What is the capacity?
2.What is the working pressure?
3.How about the inlet and the outlet pressure?
4.What is the inlet temperature?
Part 7. Why Choose Our Company
1) Our team is highly qualied and experienced;
2) We focus on providing excellent quality products;
3) Our products is energy-saving and environment-friendly;
4) Our price is reasonable and competitive based on the same quality level;
5) Excellent after-sale service.
