Braiding Machine for Carbon Fiber
US$ 60,000 - 80,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Xuzhou Qixing
Model Number:
110
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Carbon Fiber New Materials Braiding MachineUS$ 2,000 - 4,000MOQ: 1 Set -
Steel Wire Braiding Machine for High SpeedUS$ 100 - 2,000MOQ: 1 Set
-
Hose Wire Braiding MachineUS$ 3,000 - 7,000MOQ: 1 Set
-
High Voltage Cable Knitting MachineUS$ 1,000 - 6,000MOQ: 1 Set
-
Shield Wire Line Knitting MachineUS$ 3,000 - 3,500MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Xuzhou Qixing
Model Number
110
After-sales Service Provided
Engineers available to service machinery overseas
Model |
QX110-192 |
Braiding head |
1(192spindles per head) |
Spindle number |
192pcs |
Bobbin number |
384pcs |
Spindle model |
Wire spindle(this spindle is suitable to braid carbon fiber ) |
the size of bobbin |
Φ58*180mm |
The motor power |
1.1kw*4 380V 3phrase 4P |
Impeller speed |
200-240rpm |
Machine size (L*W*H) |
5000*4880*3530(for reference ) |
Weight |
2650kg(for reference) |
Braided range |
Φ80-215mm |
Delivery time |
100days |
Applications |
Carbon fiber rope band |
Packing |
Plywood |
Braiding direction |
horizonal |
|
