Home > Manufacturing & Processing Machinery > Textile Machinery & Parts > Knitting Machine > Lace Braiding Machine

Lace Braiding Machine

US$ 8,000 - 16,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Product Type:

Other, lace

Type:

Jacquard

Contact Supplier Request Quote Chat Now

Xuzhou Qixing Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Product Type Other, lace

Type Jacquard

Place of Origin China

Brand Name QX

Model Number QX-BL

Computerized Yes

Specifications

1, computer control
2, 64/96/128 spindles
3, best quality!!

Model	QX-BL64	QX-BL96
Spindle number	64	96
Max. width of lace	150mm	250mm
Braiding Speed	300 cross/minute	300 cross/minute
Main motor	0.75KW/380V(3PH)	0.75KW/380V(3PH)
Take up speed	0.01-3mm/cross	0.01-3mm/cross

Adopt the computer and control, frequency conversion adjusts the speed, high speed high-efficient, operate studying simple and easily; Used for weaving various kinds of top-grade underwear and decorating the lace; Can use various kinds of, such as cotton, rough, nylon, polyamide fibre, dacron, synthetic fibers,etc. to weave raw materials .

The display screen & Control cabinet

The colored liquid crystal display of large screen, adopt the advanced computer procedure , the menu type is operated, It is simpler to enable operating. Heavy to show amount of information, production management is convenient to control, computer store several hundred a kind of person who spends support and select and transfer at any time. Have abandonned the working miscellaneously of the traditional lace loom, has shortenned the time to change the taking type greatly, Improved production efficiency greatly at the same time .

Weave the part

Adopt and excel in the wear-resisting new materials, so vibration is small, the noise is light, Fast, the output is high, it doesn't need very chance to change speed. Intelligent control way, does not need operating artificial and handly, it is more accurate that one is fetched, The range is wider, have fully embodied the design theory that is based on people.

The lace is designed the system

The design system with strong and perfect function can satisfy various kinds of requests of the designer's , Make the designer free out from the superfluous design in great numbers while working, create newer and better type of flower. The design work with no paper makes the cost reduce too, involve efficiency to improve, the design cycle of the lace accelerates, More easy to manage.

The pulling force tester of spring

The pulling force tester of spring adopts the high stability sensor and single intelligent tester that aircrews become, It has and count apparent, function of restoring to the throne since relatively, memory trouble show etc accurate measurement operating simple, multiple functionally.

QXBL series computer lace braiding machine, which is based on the traditional band crochet, is to replace the hand with machines in operation. After some renovation, a latest model of knitting machine is produced. It can well imitate the hand knitting and weave all kinds of laces, with a quality and unification of the laces that cannot be reached by any hand knitting. Laces produced by this kind of machine are widely used on all kinds of slap-up costumes, under-wears, curtains, shoes &caps and bed clothing, etc.

The machines reduce the heavy labor of the people. One worker can simultaneously operate several machines. The number of workers saving machinery to reduce the cost of production.

Our machines have an ingenious structure with fine quality parts. The new design is free from the old mechanical paper card technique and the related mechanical driving setup, thus making it more reliable in operation with few malfunctions. The laces produced by this machine are of high quality and beautiful, while this cannot be achieved by the old mechanical machines. With high production capacity, low vibration, long life and easy maintenance, make this machine widely welcomed and used.

The machine can weave the different quality of the raw materials, such as cotton, hemp, silk, wool and various chemical fibers. The machine has no need of auxiliary equipment. The machine will be able to proceed with production, less investment and the good results. The machine has three types QXBL-64, QXBL-96 and QXBL-128.

The machine is adopt with computer-control, frequency conversion speed adjuster, and have the advantages of high-efficient, easy-learning and operation; Used for weaving various kinds of top-grade underwear and decorating the lace; It is also suitable for various kinds of materials, such as cotton, rough, nylon, polyamide fiber, synthetic fibers, etc.

Mail us to get machine video!!
