Automatic Laminating Machine MF1600-M1 Manual Cold Laminator, Single Side LaminatorUS$ 950 - 1,550MOQ: 1 Set
Auto Cold Laminator
1.Thin self-adhesive is available and will be no wrinkle, and the deep color images can be laminated strongly.
2. Lower cost, improve quality
3. Laminating at 50℃ can avoid bubbles and snowflakes;
4. High efficiency laminating and high-yield,
5. The entire 50-meter media will not slant;
6. Auto tear-off backing paper function;
7. One man or unmanned operation can be achieved for laminating 400sq.m/h;
Applications:
Suitable for the fields of indoor advertising, outdoor self-adhesive vinyl, graphic image, frameless pictures, etc.;
All the traditional cold laminating industry.
Technical Parameters:
Parameter |
LF1600-M1 |
LF1700-M1 |
Max Lamination Width |
1520mm/60” |
1630mm/64” |
Max Lamination Thickness |
23mm/0.9” |
23mm/0.9” |
Max Speed |
6m/min |
6m/min |
Max Temp |
60C/140F |
60C/140F |
Pressure/Height adjust |
Manual |
Manual |
Heating |
Infrared |
Infrared |
Preheating time |
5-10 min |
5-10 min |
Power Consumption |
0.8-1 kw/h |
0.8-1 kw/h |
Power Input |
1400w |
1400w |
Voltage |
110V/220V |
110V/220V |
N.W. |
150KGS |
170KGS |
Optimum Performance:
Heat-assist cold lamination for bubble-free application
Adjustable settings for increased capacity and versatility
Fast processing with a speed up to 6m/min
Unique anti-tilt and anti-fold system ensures clear output
Roll to roll capacity
Ease of Use:
Manual nip gap adjustment
Simple film tension adjustment
Light weight drop-in supply shafts with auto-grip for easy loading
Foot pedal switch for pieces accurate application
Safety:
Foot switch for hands free operation
Laser safety eyes and 1 emergency stop
CE
