Specifications
1.Appearance:Silver gray metallic luster2.Standard:ASTM B 386-2003
3.Density:>=10.2g/cm3
4.Size:0.3mm<=Dia<=0.8mm
1.Appearance:Silver gray metallic luster
2.Standard:ASTM B 386-2003
3.Density:>=10.2g/cm3
4.Size:0.3mm<=Dia<=0.8mm
5.Test report of Mo
6.Application:
(1) Circles the filament core, the support wire, the lead-out wire, the electronics grid and so on.
(2) The support silk, the lead-out wire guide rod, the electricity vacuum components, the heater element, the high temp electric resistance furnace gives off heat the material and so on.
(3) Advantage of our Mo wire for Crystal growth applications:
- long term stock for your ready to use
- smoothed forged and chemically cleaned surface with quality
- uniform grain with densified microstructure ensures longer life time
- ready for use parts with precise machining tolerance.
Diameter(μm) |
Weight/200mmmg |
Weight/200mm tolerance |
Diameter tolerance % |
30≤d≤40 |
1.47 -2.61 |
±3.0 |
---- |
40<d≤100 |
>2.61 – 16.33 |
±3.0 |
7.0 |
100<d≤400 |
>16.33 – 256.2 |
±3.0 |
---- |
400<d≤600 |
---- |
---- |
±2.5 |
600<d≤2500 |
----- |
----- |
±2.0 |
Chemical composition
| Content of molybdenum | Content of all other elements | Content of each element |
| ≥99.95% | ≤0.05% | ≤0.01% |
Quick Details
| Wire Gauge: 0.04''--2'' | color: silvery white | surface: ground |
| processing method: pressing | processing equipment: pressing machine | fineness: ASTM standard |
| the depth of parallelism: ASTM standard | tolorance: ASTM standard | purity: >99.95% |
| payment method: T/T, L/C,Escrow | packaging: wooden cases |
Elments |
Mo | O | N | C | Si | Fe | Ni |
| Content | 99.96Min. | 0.005 | 0.002 | 0.01 | 0.001 | 0.0019 | 0.0011 |
Specification
| Molybdenum rod | Molybdenum wire | Molybdenum wire for spraying | ||||
| diameter(mm) | explanation | diameter (mm) | explanation | diameter (mm) | Toleranceof Dia. | explanation |
| 3.0~60.0 | used for ground rods and polishing rods | 0.08∼0.25 | coiling | 1.41∼2.0 | -0.04∼+0 | With lead milk on the surface in black color, single weight can be discussed |
| 0.25∼1.0 | Straight or rolling | 2.01∼3.0 | -0.05∼+0 | |||
| 1.0∼3.0 | Rolling ,or straight with ground finished | 3.0∼3.8 | -0.05∼+0 | |||
Package details:
First, packaging with moisture-proof paper
Second, packaging with kraft paper
Third, packaging with foam plastics in all side of plywood case.
Finally packing products in plywood case
Baoji zhipu non-ferrous metals processing Co.,Ltd
Address:Torch road ,gaoxin district,baoji city,Shaanxi province,China(mainland)
Skype:Cbjzp
Tel:86-0917-3601711
Fax:86-0917-3602511
TM:cn1510696876
