Help CenterDual Pointer Gauge
Related Products
dual pointer gauge
Two gauges in one design.
It's specifically designed for hot water boilers.
It measure the pressure of water in PSI and KPA, plus temperature in C° and °F.
The large square and round dial is easy to read.
Technique Specification:
1. Dial Size: L92.5mm*W92.5mm*H39mm
2. Pressure Range: 0~75 PSI KPA
Temperature Range: 20~120 C F
(customer-made pressure and temperature range is available)
3. Accuracy:
Pressure: ±3-2-3% of full scale
Temperature: ±2%
4. Connection: Bottom Conn.
5. Connection Size: 1/2"NPT, Customer-made is available.
6. Bezel: Pressed
7. Stem Length: 67mm * Φ9mm
Material Details:
1. Case Material: Black Steel
2. Dial Material: Aluminum
3. Window/Lens: Glass
4. Inner Material:
Pressure: Brass Bourdon Tube
Temperature: Bimetal
Packing details:
1pc/small box,
50pcs/CTN
