High Quality Low cost PV Inverter House Reusable Prefab Container
Specifications:
1. Low cost & high quality
2. Anti-corrosion, water&fire proof
3. Easy assembled and reassembled
4. Easy move and transporting
5. Fast delivery
| Main structure Specification(Standard) | ||
| L*W*H | 10GP 2991*2438*2896mm | 1.6 steel plate,Container weight:2000KG |
| 20GP 6058*2438*2896mm | 1.6 steel plate,Container weight:3600KG | |
| 40GP 12192*2438*2896mm | 1.6 steel plate,Container weight:8000KG | |
| Other components specification | ||
| Insulated color steel plate | 0.5mm steel+50mm rockwool +0.5mm steel | |
| Side plate | 1.6mm | CORTEN A(Special container steel)or 50mm color steel plate, 0.5mm thick steel plate |
| Roof plate | 2.0mm | CORTEN A |
| Door plate | 1.8mm | CORTEN A |
| Bottom beam | 4.0mm | Q235 Steel |
| Column | 4.0mm | CORTEN A |
| Door column | 3.0mm | Q235 Steel |
| Air duct | 1.0mm | SPCC(galvanized plate) |
| Space | Can load 2pcs inverters,2PCS DC power distribution cabinets and monitor system | |
| Features | ||
| 1. Fit enviroment: Working temprature:-30°C~50°C; Relative humidity: 0~95% without condensing; Highest elevation:6000M; | ||
| 2. Can intergratedly load battery pack,inverter,transformer,junction box, and other devices into a single 40 FT or 20 FT container, easy for system transportation and installation; | ||
| 3. Installation only needs container positioning and input and output cable connection, only need one day from installation to using; | ||
| 4. Container shell can be recycled and reused; | ||
| 5. High power density design, small size, light weight, saving space, low bearing requirements; | ||
| 6. Unique intake air design, good dustproof performance; container with 2 designs of bottom and side intake air, with high quality dust screen to achieve the best dustproof performance; | ||
| 7. Standard container steel plate, high mechanical strength, surface passivation treatment, metal welded frame structure, with excellent mechanical strength and longer service life; | ||
| 8. Dust prevention design, filter and dust proof louver with super heat solutions, increased the system safety and reliability, improved system power generation efficiency and capacity, is the best solution for integrated photovoltaic power station. | ||
| Fit scenes | ||
| MW Level photovoltaic power station | ||
| Protection level | ||
| Protection level:IP65;Fire resistance:Level A;Anti-earthquake:Level 7;Wind resistance:Level 12; | ||
| Durablity | ||
| 25 Years(25°C,60% humidity) | ||
Product Details:
Company Profile:
PuYuan HongYe Technology Co., LTD was established in 2008, specializing in intelligent modular house research and development, manufacturing, sales, installation and service.Our main products include: packed container house, expandable container house,movable toilet, movable security kiosk,modular shop,modular container villa, light steel villa, etc.,all products with high quality and favorable price. The products can be customized,we offer diversified service to serve well our customers. We have become one of the best high-tech modular house manufacturers in China now.
Branches:
SHENZHEN PUYUAN NEW MATERIALS CO.,LTD.
SHENZHEN PUYUAN XINGYE INVESTMENT CO., LTD
SHENZHEN ANJIAN MODULAR HOUSE MATERIALS CO., LTD
SHENZHEN ANJIAN MINGZHU ENGINEERING CO., LTD
SHENZHEN PUYUAN HENGTONG NEW ENERGY VEHICHLES TECHONOLOGY CO., LTD
HUIZHOU PUYUAN NEW COLOR STEEL SANDWICH PANEL MATERIALS CO., LTD
Production Process:
Our Factory:
Our Team:
Package and Transportation:
Packaging Details: Standard seaworthy packing
Shipping:Ocean Shipping.
Delivery Time: 20-30days
Our customers from worldwide:
Q&A:
Q1: What’s the MOQ, can I buy 1 sample piece at the first time?
Re: You can buy 1 sample piece for the 1st time, the MOQ is 8 units.
Q2: What’s the delivery time?
Re: Normally 20-30days after getting deposit.
Q3: What’s the payment method?
Re: TT and L/C are acceptable, we prefer 30% TT deposit in advance, and 70% balance before shipment.
