Summarize
This machine belongs to four roller plate rolling machine. It’s for pre-bending and rolling of barrels used
on pressure vessels and other industry. It has the ability of rough straightening and round rolling as
well.
The top roller is used as main drive. It’s hydraulic driven. It drives the bottom roller and side rollers
through the friction between the plate and the roller, and thus to provide rolling torque. The lifting
of the bottom roller, the two side rollers, tilting frame, and the backup roller is through hydraulic.
The pre-bending of plate end is achieve by lifting the bottom roller and clamping the plate end,
meanwhile, inclined lifting the side rollers. The advantage of end plate bending (pre-bending)
and rolling can be conducted on the same machine.
Structure and main parts
This equipment composed of work frame, upper roll device, main drive device, down roll device, side roll
device, overturn device, hydraulic system (parts), electricity system (parts), and lubricate device.
4 Roller Bending Machine Parameters
Model |
Max bending thickness |
Max bending width |
Bending capacity |
Pre- bending capacity |
Top roller diameter |
Bottom roller diameter |
Side roller diameter |
Bending speed |
Main hydraulic motor |
Working roll drive mode |
W12-12*4000 |
12 |
4000 |
245 |
10 |
410 |
360 |
280 |
4 |
30 |
hydraulic |
W12-16*2000 |
16 |
2000 |
245 |
12 |
300 |
300 |
220 |
5.5 |
18.5 |
hydraulic |
W12-16*2500 |
16 |
2500 |
245 |
12 |
330 |
330 |
260 |
6.5 |
22 |
hydraulic |
W12-20*2000 |
20 |
2000 |
245 |
16 |
330 |
330 |
260 |
6.5 |
22 |
hydraulic |
W12-20*2500 |
20 |
2500 |
245 |
16 |
360 |
360 |
280 |
6.5 |
30 |
hydraulic |
W12-20*3000 |
20 |
3000 |
245 |
16 |
410 |
400 |
320 |
4.5 |
37 |
hydraulic |
W12-25*2000 |
25 |
2000 |
245 |
22 |
360 |
360 |
280 |
6.5 |
30 |
hydraulic |
W12-25*2500 |
25 |
2000 |
245 |
22 |
410 |
400 |
320 |
5 |
37 |
hydraulic |
Besco Machinery Limited is professional on manufacturing mechanical power press, pneumatic power press, hydraulic press, press brake, shearing machine, plate bending and rolling machine, profile bending and rolling machines, cut to length and slitting line, etc.
We have 18 years experience on manufacture metal working machines and we export our machines to all the worldwide market and have the best response from customers.
We will offer you our best quality machine and the after sale service.
1. Free installation, trial start and adjustment, training. But the machine quotation does not include the charges of our engineers in the buyer’s country if you want, and the buyer must take charge of all the expenditure including airplane tickets of our engineers when in the buyer’s country to do the service!
2. Warranty period is1 year. During the warranty period we shall reply to the call or Fax from the user for the machine faults (expect for faults caused by no abiding by the relevant operation regulations, or by force injury) within 24 hours.
Question1: What is about the payment?
Answer:Payment:30% T/T as advance, 70% T/T before delivery.
Question2: what is about the delivery time?
Answer:That depend on the stocks.
