Machine Body
The machine body is in an overall processed structure and ANSYS finlte element analysis to main parts of the machine body for analysis,which has ensure the reliability of machine tool and the precision of the entire machine.
Oil Cylinder
Electrohydraulic servo valve imported from Germany and imported grating ruler is adopted for the main oil cylinders on both sides,to brake through the stroke control pattern of traditional bending machines of stopper type,typical of high feedback precision for position of gliding block,accurate and stable operation, good synchronizing performance and high repeated positioning precision of gliding block.
Rear Stopper
Imported parts are used for all the functional parts in the rear stopper to ensure the stopper percision and the mechanism of real stopper will multiple stopping shafts for more complete function is employed up to customer requirement.
Hydraulic control system
Hydraulic control system import from germany is adopted for the whole hydraulic system,simplify the installation of pipelines to ensure stable operation as well as simple and nice appearance of the machine tool.
Grating Ruler
C-shaped plates are fitted on both sides of the machine body,the high precision grating rule is
mounted on theC-shape plates,thus to avoid the infuence over pending precision arising from
distortion of machine body during bending process.
Technical Parameter
Type |
Nominal Pressure (KN) |
Length of Table (mm) |
Distance between Housings (mm) |
Throat Depth (mm) |
Stroke (mm) |
Open Height (mm) |
Main Motor(KW) |
WC67Y-63/2500 |
630 |
2500 |
2050 |
250 |
100 |
335 |
5.5 |
WC67Y-63/3200 |
630 |
3200 |
2670 |
250 |
100 |
335 |
5.5 |
WC67Y-63/4000 |
630 |
4000 |
3300 |
250 |
100 |
350 |
5.5 |
WC67Y-80/2500 |
800 |
2500 |
2050 |
250 |
100 |
335 |
7.5 |
WC67Y-80/3200 |
800 |
3200 |
2660 |
250 |
100 |
335 |
7.5 |
WC67Y-100/2500 |
1000 |
2500 |
1950 |
320 |
140 |
385 |
7.5 |
WC67Y-100/3200 |
1000 |
3200 |
2650 |
320 |
140 |
385 |
7.5 |
WC67Y-100/3600 |
1000 |
3600 |
3000 |
320 |
140 |
385 |
7.5 |
WC67Y-100/4000 |
1000 |
4000 |
3200 |
320 |
140 |
385 |
7.5 |
WC67Y-100/5000 |
1000 |
5000 |
4200 |
320 |
150 |
420 |
7.5 |
WC67Y-125/3200 |
1250 |
3200 |
2680 |
320 |
150 |
370 |
7.5 |
WC67Y-125/3600 |
1250 |
3600 |
3000 |
320 |
150 |
370 |
7.5 |
WC67Y-125/4000 |
1250 |
4000 |
3280 |
320 |
150 |
370 |
7.5 |
Besco Machinery Limited is professional on manufacturing mechanical power press, pneumatic power press, hydraulic press, press brake, shearing machine, plate bending and rolling machine, profile bending and rolling machines, cut to length and slitting line, etc.
We have 18 years experience on manufacture metal working machines and we export our machines to all the worldwide market and have the best response from customers.
We will offer you our best quality machine and the after sale service.
1. Free installation, trial start and adjustment, training. But the machine quotation does not include the charges of our engineers in the buyer’s country if you want, and the buyer must take charge of all the expenditure including airplane tickets of our engineers when in the buyer’s country to do the service!
2. Warranty period is1 year. During the warranty period we shall reply to the call or Fax from the user for the machine faults (expect for faults caused by no abiding by the relevant operation regulations, or by force injury) within 24 hours.
Question1: What is about the payment?
Answer:Payment:30% T/T as advance, 70% T/T before delivery.
Question2: what is about the delivery time?
Answer:That depend on the stocks.
