Specifications
- 7lm high brightness light source- highest standard
- best quality power supply
- rotate tube cap
- individual packaging
Introduction
LED T8 Tubes are designed to replace the equivalent Cathode Fluorescent tubes. By using only 1/3 traditional tubes’ electricity, the LED tubes have the same structure and style of traditional CFT tubes but delivers a brighter performance per watt, with less heat radiation and few of the pitfalls faced by traditional CFT tubes. There are no toxic gasses present in the design and the tubes are much more robust and weather, shock resistant. The LED T8 Tubes can be widely used for indoor applications.
1) Transparent Cover |
2) Milky White Cover |
3) 180 degree rotatable end caps for the transparent cover tube |
Features
- High Brightness SMD LED sources to maintain longer lasting operation life and produce even lighting.
- Transparent or milk-white PC cover, not easy breakable. Aluminum PCB and base for excellent heat radiation
- Easily to replace traditional fluorescent tubes
- When the current is 20mA, within 1000 hours, attenuation is less than 3%
- Excellent colour consistency, no chromatic aberration.
- No UV, IR, mercury or other hazardous substance
- Instantly turns on, no flickering and interference
- Packaging: 1pc/round high protection box; 25pcs/carton
- 180 degree rotate tube cap
- Each tube comes with pin protectors for safety purpose on delivery
Specifications
Tube Length |
604mm |
1213mm |
1507mm |
|
Power Consumption |
8W |
18W |
23W |
|
LED Qty |
144pcs |
288pcs |
324pcs |
|
Lumen |
910-1050lm/650-780lm |
1810-2100lm/1300-1480lm |
2100-2350lm/1460-1600lm |
|
Net Weight |
205g |
410g |
750g |
|
LED Source |
TAIWAN EVER LIGHT SMD3528 |
|||
Base |
G13 |
|||
Material |
Aluminum base, PC cover (Transparent/ Milky white), Aluminum PCB |
|||
Light Transmittance |
≥95 clear cover, ≥90 frosted cover, ≥88 milky cover |
|||
Colour Temperature |
Cool White6500k / Natural White 4500k / Warm White 3000k |
|||
Beam Angle |
120° |
|||
Input Voltage |
AC110V/ 220-240V |
|||
Current |
60mA |
|||
Frequency |
50-60Hz |
|||
PFC |
>0.85 |
|||
Working Temperature |
-20 °C – 40° C |
|||
Storage Temperature |
-20 °C – 60° C |
|||
Working Humidity |
30% - 40% |
|||
Storage Humidity |
10% - 90% |
|||
LED Life Span |
50,000h |
|||
Warranty |
2 years |
|||
LED TUBE
LED T8 TUBE
LED SMD3528 TUBE
