Ethernet Networking utp cat6/cat5 RJ45 Keystone jack, cat5 cat6 solution network module
Features:
- Housing : high temperature thermoplastic
- Covered with metal that provides well anti-EMI performance
- Contract : phosphor bronze , phosphor bronze with 6 to 50 u " gold plate .
- Available in Cat 5e,T568 A ,T568 B wiring .meeting every cabling requirement
- Accept 22-26 AWG solid with a insulation diameter of 0.4-0.6 mm
- Easy to be terminated Low attenuation loss and high return loss .
- High reliability and superior performance .
electrics:
1.According to UL 1863
2.Current rating: 1.5 Amp Max.
3.Voltage rating: 150 Volts
4.Contact resistance: 20 m-ohm
5.Insulation Resistance: 500M-ohm
6.Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min
materials:
Housing: PC UL94V-0
Housing: PC UL94V-0
IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.
PCB: FR4 1.6mm(0.04") thickness, 2 layers
Contact: PC Ul94V-0, 0.45mm(0.018") Diameter Phosphor bronze with 3 U" to 50 U" Gold plating on contact
Pictures:
Company information:
Payment and Delievey:
Payment : L/C, T/T, Western Union, Moneygram,Paypal as well as Cash acceptable
Delievery: Shipment is usually delivered within 1-5 working days after receiving payment.The goods is usually sent by express way(TNT,UPS,FEDEX,DHL,EMS or other special way) or by ship as per customers' exact quantity and requirement.
