VOL-OCK6-U8 RJ45 8P8C Unshielded Cat6 Keystone Jack with shutter
Description
3M Cat6 unshielded module can be independently placed on 3M 24 port empty frame, panel. Spring door module interface designed to effectively prevent dust from entering the module side sliding buckle design, more effectively lock cable, can not easily be stretched to break, toolless pressure line method, more quick and easy, threading cap mark T568A / B 2 standard play law. Original quality, polycarbonate plastic, engineering preferred products.
Feature
1, through continuous impedance lilies, terminals, printed circuit analysis, optimal impedance matching relations;
2, gilded lilies, prevent surface oxidation, improve the contact performance, to ensure the performance and service life;
3, using high-quality fire-retardant polycarbonate material, flame retardant UL94V-0 level reached;
4, support for mainstream termination approach to ensure universal connectivity and reliability of the connection;
5, compact form factor designed to ensure the end of the cable box to accommodate more relaxed space.
Technical Parameters
1, the DC resistance: ≤300mΩ;
2, the contact resistance: ≤20mΩ;
3, Compressive strength: 1000V (AC750V) 1min without breakdown and flashover;
4, insulation resistance: ≥1000mΩ;
5, lilies: phosphor bronze, gold-plated;
6, IDC Terminal: Phosphor bronze, card access 22-26AWG conductor;
7, the number of mating plug and socket ≥750 times;
8, storage temperature: -40 ℃ ~ 70 ℃;
9, the installation temperature: -10 ℃ ~ 60 ℃;
10, the working temperature: -10 ℃ ~ 60 ℃;
Payment and Delievery
Payment : L/C, T/T, Western Union, Moneygram,Paypal as well as Cash acceptable
Delievery: Shipment is usually delivered within 1-5 working days after receiving payment.The goods is usually sent by express way(TNT,UPS,FEDEX,DHL,EMS or other special way) or by ship as per customers' exact quantity and requirement.
