Alibaba Gigabit Ethernet 10/100M fiber optic media converter,2-port ethernet switch with cheap price
Description:
1.It can be inserted into rack-mount chassis or inserted into standalone shell.
2.The converter mediates between a 10/100 Base-TX segment and a 100Base-FX segment.
3.It is primarily designed for large, higher speed/ bandwidth demanding work groups that require expansion of the Ethernet network.
4.It can extend the conventional 10M Ethernet or 10/100M fast Ethernet to 2km~80km via the fast Ethernet fiber optical line.
5.It is high~performance, cost effective and flexible solutions for a wide range of applications in the field of~broad~band WAN established by data network operators as Telecast, Netcom, Unicom, or industrial broadband industrial personalized network of government, finance,oil, police, force, railway, power, transportation, education, etc.
Features:
1.Support one 10/100/1000Base-T Gigabit Ethernet UTP port and one 1000Base-SX / LX Gigabit Ethernet Fiber port
2.It can be inserted into rack-mount chassis or inserted into stand-alone shell.
3.Extend fiber distance up to 2km for 50/125um or 62.5/125um multi-mode fiber and 20-80km for 9/125um single-mode fiber
4.Indication light: POW: Power Indicator, 10/100: Speed Indicator, LINK/ACT
5.Auto-negotiation of 10/100Mbs rate and Auto-MDI/MDIX for TX port
6.Auto-detection of half/full duplex transfer mode for TX port
7. Provide switch configuration of half/full duplex transfer mode for FX port
8.Transmission Indicator, FDX: Full-duplex or half duplex Indicator, FX: Fiber Indicator,
9.TX: Raster Line Indicator etc.
Specifications:
parameter |
Specifications |
Access mode |
10/100/1000Mbps Gigabit Ethernet |
Standard |
IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T , IEEE802.3z 1000Base-SX/LX Gigabit thernet,IEEE802.1qVLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree |
Wavelength |
850nm/1310nm/1550nm |
Transmission distance |
multi-mode Dual-fiber: 220m (62.5/125um)/550m (50/125um)
single mode Dual-fiber: 20/40/60/80 Km
single mode Single fiber: 20/40/60/80 Km
Category-5 twisted pairs: 100m
|
Port |
One RJ45 port:
Connecting with STP/UTP category-5 twisted pairs
One optical port:
Multi-mode Dual-fiber: SC (50, 62.5/125um)
Single mode Dual-fiber: SC/FC (9/125um)
Single mode Single fiber: SC/FC (9/125um)
|
Conversion means |
Media conversion |
Delay |
<10us |
BER |
<10-9 |
MTBF |
100,000 hours |
LED indicator |
PWR ,100M;FXL,1000M,TX,RX; |
Power supply |
AC220 0.5A/DC-48 (built-in) |
Power consumption |
5W |
Operating temperature |
-10~55°C |
Operating humidity |
5%~90% |
Storage temperature |
-40~70°C |
Maintaining humidity |
5% ~ 90% non-condensing |
Dimensions |
95mm*70mm*25mm(external power supply) |
Pictures:
1.Payment : L/C, T/T, Western Union, Moneygram,Paypal as well as Cash acceptable
2.Delievery: Shipment is usually delivered within 1-5 working days after receiving payment.The goods is usually sent by express way(TNT,UPS,FEDEX,DHL,EMS or other special way) or by ship as per customers' exact quantity and requirement.
