Hot sale fc upc 1*2 fiber optic PLC splitter, steed tube mini fiber 1:2 optical splitter
Description
Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations. It features small size, high reliability, wide operating wavelength range and good channel-to-channel uniformity, and is widely used in PON networks to realize optical signal power splitting as a low-cost solutions.
All products meet TBC-1209-CORE and TBC-1221-CORE requirements.
Features
1. Low Insertion loss
2. Broadband operating
3. Excellent uniformity
4. SC/FC/ST fiber port optional
5. External power supply.
6. The quality is more credible and stable
Applications
1. FTTH&FTTX
2. Other optical transmission systems
3. Optical Signal Distribution
4. Telecommunication Network and fiber optic sensors
Specifications
1*N fiber optic splitter
| Parameter for PLC Splitter | |||||||
Parameter |
1x2 | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | |
Attenuation Value(dB) |
≤3.7 | ≤7.5 | ≤11 | ≤14.5 | ≤18 | ≤22 | |
Loss Uniformity(dB) |
≤0.8 | ≤0.8 | ≤1.0 | ≤1.4 | ≤1.9 | ≤2.5 | |
Return Loss(dB) |
APC | ≥60 | |||||
| UPC | ≥60 | ||||||
PDL(dB) |
≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | |
Directivity(dB) |
≥55 | ≥55 | ≥55 | ≥55 | ≥55 | ≥55 | |
Operating Temperature(oC) |
-40~85 | ||||||
Storage Temperature(oC) |
-40~85 | ||||||
Operating Bandwidth(nm) |
±40 | ||||||
Operating Wavelength(nm) |
1260~1650 | ||||||
2*N fiber optic splitter
parameter2×2 |
2×2 |
2 ×4 |
2×8 |
2×16 |
2×32 |
2×64 |
operating wavelength(nm) |
1260- 1650 |
|||||
insertion loss(dB) |
4.3 |
7.6 |
10.8 |
14.3 |
17.5 |
20.7 |
loss uniformity (dB) |
0.8 |
1 |
1.2 |
1.5 |
1.8 |
2 |
return loss(dB) |
55 |
55 |
55 |
55 |
55 |
55 |
PDL(DB) |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
directivity(dB) |
55 |
55 |
55 |
55 |
55 |
55 |
operating wavelength(nm) |
-40~+85 |
|||||
storage temperature(℃) |
-40~+85 |
|||||
fiber type |
G657 or customer specification |
|||||
pigtail length |
customer specification |
|||||
Pictures
Payment and Delievery
Payment : T/T, Western Union, Moneygram,Paypal as well as Cash acceptable
Delievery: Shipment is usually delivered within 1-5 working days after receiving payment.The goods is usually sent by express way(TNT,UPS,FEDEX,DHL,EMS or other special way) or by ship as per customers' exact quantity and requirement.
