Help CenterIrrigation Machine 75-400
Related Products
Technical advanced supply Sprinkler:
1,Special PE pipe Dia. 75mm,PE pipe length: 400m,
2. Spray gun SR101, maximum range 40-50m
3,Nozzle dia. 14 mm - 22mm.
4,Drive with TX20 full flow turbine.
5,BAUER 2–speed gearbox with brake.
6,LCD screen for speed meter.
7,Equipped with hydraulic pressure gauge.
9,Equipped rotary chassis, can make the reel drum rotation within the range of 270 °
10,2–wheel undercarriage with adjustable track width and jack.
11,Equipped with speed compensation mechanism.
12,Equipped with precise speed control device.
13,Automatic cart lifting safety device for wheel cart.
14,wheel cart for symmetric PE-pipe retraction with adjustable track width;
16,All steel structure via hot dip galvanized.
Performance data:
1, Strip width: 50-75m .
3, Connection pressure: 4.5-10.bar,
4, Water flow:13.-30. m3/h.
5, Precipitation rate: 8mm – 50mm
6, Spraying uniformity coefficient: ≥95
7, Retraction speed uniformity, adjustment range : 0-46 m/h.
Service life: 15 years
