Product Details
Place of Origin: | Shanghai, China | Brand Name: | TOMA | Model Number: | TM200 |
Product Description
TOMA Central rolling shutter motor
1. Central rolling shutter motor(One set includes 1 pc motor,6.5m brake cable,4.5m power cable 4 lines,1 pc mini switch,1 pc instruction)
2. A safe and easy-to-use system in one model,suitable for different tyoe of posts and sprins. The TM200/60-H,TM240/70-H series operators allow for modular installion without the need to make any adaptations. Safe and raliable of the maximum power verastile in every way. All of the TM200/60-H, TM240/76-H series operators are suitable for Φ200-260 mm springs. Flexibility of use and powerful lift, all in one model. The TM200/60-H, TM200/76-H series operators are the optimal solution provide automation to all types of rolling shutters without needing to modify original structure of the shutters.
Description:
Item name | Model | Torque | RPM | Cut Out Temperature | power | Consumption | Lifting weight | Tube Rolling | Pulley |
Central rolling shutter motor (One set includes 1 pc motor,6.5m brake cable,4.5m power cable 4 lines,1 pc mini switch,1 pc instruction) | 230V/50Hz | (NM) | (MIN) | (W) | (A) | (Kg) | (mm) | (mm) | |
TM200/60-120H | 120 | 10 | 4 | 460 | 2 | 120 | 60 | 200-220 | |
TM200/60-150H | 150 | 10 | 4 | 600 | 2.6 | 160 | 60 | 200-220 | |
TM200/60-180H | 180 | 10 | 4 | 750 | 3.26 | 200 | 60 | 200-220 | |
TM240/76-420H | 420 | 10 | 4 | 1000 | 4.36 | 360 | 76 | 240-260 | |
TM200/60-120R | 120 | 10 | 4 | 460 | 2 | 120 | 60 | 200-220 | |
TM200/60-150R | 150 | 10 | 4 | 600 | 2.6 | 160 | 60 | 200-220 | |
TM200/60-180R | 180 | 10 | 4 | 750 | 3.26 | 200 | 60 | 200-220 | |
photocell | TMPC1 | / | |||||||
alarm lamp | AL01A-220V | / | 220V | ||||||
"200"Means tube diameter,"60"Means inside diameter,"120"Means torque,"H"Means with handle control |
Picture:
