Sliding gate opener

TOMA Sliding gate opener series

Full Set ( one motor, 1 control box, 2 transmitters, mounting accessories)

Function:

Built-in control board, Terminals for Push button,Photocell, Flash lamp,Auto-closing is available, time delay is adjustable, In case of power failure,the gate can be opened and closed manually after release clutch.

Technic data:

mechanical imit switch

With built in receiver

Motor power:AC220V/AC110V

Frequency:50(60)Hz,

W.T(kg):16kg,

Motor rotational speed:1400 r/min, Output rotational speed:46.7r/min,

Maximum gate weight:1200kg

Reduce ratio:30:1,

Gear Box material:Aluminum alloy
