Needle Roller Bearing TARN 3570
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Brand Name | YNR | Bore Size | 35, | |
| Outside Diameter | 70, | Model Number | TARN 3570 | |
| Precision Rating | P0 | Seals Type | Open | |
| Number of Row | Single Row | Place of Origin | Jiangsu, China |
Product Description
Needle Roller Bearing TARN 3570
Nanjing Younarui Bearing Co., Ltd main products includes: Cylindrical roller bearing, Angular contact ball bearing, Deep groove ball bearing, Taper roller bearing, thrust roller bearing, thrust ball bearing, Self-aligning roller bearing, Needle roller bearing, Linear guide bearing, Slewing bearing, Bearing housing and accessories. Please enquriy us for above or special bearings according to your applications.
| BALL BEARING | ROLLER BEARING | SPECIAL BEARING | OEM BEARING | OTHERS | ACCESSORIES |
YNR Needl Roller Bearing TARN 3570
YNR Needle roller bearings have an internal design based on needle or cylindrical roller bearings. They have a thick-walled outer ring, which enables them to accommodate high radial loads, while reducing distortion and bending stresses.
The outer ring running surface is crowned as standard. However, support rollers with a cylindrical (flat) running surface are also available.
Bearing parameter (Please contact us if didn't find the bearing number you need)
| Part No. | Dimensions (MM) | Approx. | |||
| d | D | C | H | Wgt. lbs | |
| ZARN 1545 | 15 | 45 | 16 | 40 | 0.7 |
| ZARN 1747 | 17 | 47 | 16 | 43 | 0.8 |
| ZARN 2052 | 20 | 52 | 16 | 46 | 0.9 |
| ZARN 2062 | 20 | 62 | 20 | 60 | 1.9 |
| ZARN 2557 | 25 | 57 | 20 | 50 | 1.2 |
| ZARN 2572 | 25 | 72 | 20 | 60 | 2.6 |
| ZARN 3062 | 30 | 62 | 20 | 50 | 1.3 |
| ZARN 3080 | 30 | 80 | 20 | 66 | 3.3 |
| ZARN 3570 | 35 | 70 | 20 | 54 | 1.8 |
| ZARN 3585 | 35 | 85 | 20 | 66 | 3.6 |
| ZARN 4075 | 40 | 75 | 20 | 54 | 2 |
| ZARN 4090 | 40 | 90 | 25 | 75 | 4.6 |
| ZARN 4580 | 45 | 80 | 25 | 60 | 2.5 |
| ZARN 45105 | 45 | 105 | 25 | 82 | 6.7 |
| ZARN 5090 | 50 | 90 | 25 | 60 | 3.2 |
| ZARN 50110 | 50 | 110 | 25 | 82 | 7.3 |
| ZARN 55115 | 55 | 115 | 25 | 82 | 7.7 |
| ZARN 60120 | 60 | 120 | 25 | 82 | 8.2 |
| ZARN 65125 | 65 | 125 | 25 | 82 | 8.8 |
| ZARN 70130 | 70 | 130 | 25 | 82 | 9 |
| ZARN 75155 | 75 | 155 | 30 | 100 | 17.4 |
| ZARN 90180 | 90 | 180 | 35 | 110 | 25.6 |
2. By Air: We can ship from Shanghai, Shenzhen, Hongkong etc.
3. By Sea: We can offer you FOB Shanghai, FOB Guangzhou etc.
4. We can also send bearings to your forwarder or agent in China, who can arrange shipment for you.
1. We are Professional bearing factory since 2004.We offer high quality bearing with competitive price.
2. 24-hour response on line and provide technical support.
3. Huge stock goods ensure you Very Short Delivery Time(Generally 1- 3 days after payment for stocks, 15 - 30 days for OEM and new items.
4. Good after-sale service (12 months quality warranty, money can be deducted or refund if any quality problem).
5. OEM/Customized service are welcomed.
6. Various kinds of bearings and brands available.
7.100% test the quality and packing before delivery.
8. Free sample available.
Our factory was founded in 2004, We are a professional manufacturer of ball bearings and roller bearings, including deep groove ball bearing, self-aligning bearing, cylindrical roller bearing, tapered roller bearings, with our good team work and hard working of skillful staffs and our professional engineers, we got very good reputation in the world market, especially in American and European countries. Thanks for every customer's support and trust, our company hope to establish mutual benefit and development business relations with you!
